| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-75-01070 | MOTOR ASS'Y | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6441 TO 6443. | ||||||
| ? | (★706-75-41091) | • BLOCK,CYLINDER | 1 | SN: K20001- |
|||
| ? | (★706-75-41163) | • PISTON SUB ASS'Y | 7 | SN: K20001- |
|||
| ? | (★706-75-42180) | • SHAFT,CENTER | 1 | SN: K20001- |
|||
| ? | (★706-75-41220) | • BALL,CENTER | 1 | SN: K20001- |
|||
| ? | (★706-75-41110) | • SPRING | 1 | SN: K20001- |
|||
| ? | (★706-75-41130) | • RING,CENTER | 1 | SN: K20001- |
|||
| ? | (★706-75-40010) | • BEARING | 1 | SN: K20001- |
|||
| ? | (★706-75-42740) | • PLATE,VALVE | 1 | SN: K20001- |
|||
| ? | (★04020-00820) | • PIN,DOWEL | 1 | SN: K20001- |
|||
| ? | (★706-75-42260) | • RETAINER | 1 | SN: K20001- |
|||
| ? | (★706-75-42661) | • SHAFT,DRIVE | 1 | SN: K20001- |
|||
| ? | (★706-75-42270) | • SCREW | 7 | SN: K20001- |
|||
| ? | (★706-75-42121) | • CASE,BRAKE | 1 | SN: K20001- |
|||
| ? | (★706-75-42880) | • BEARING | 1 | SN: K20001- |
|||
| ? | (★706-76-40890) | • BEARING | 1 | SN: K20001- |
|||
| ? | (★706-7E-11260) | • SPRING | 2 | SN: K20001- |
|||
| ? | (★706-7E-11270) | • SEAT | 1 | SN: K20001- |
|||
| ? | (★706-75-05010) | • SPACER KIT | 1 | SN: K20001- |
|||
| ? | ☆ | • • SPACER ? 5.0MM | 1 | SN: K20001- |
|||
| ? | ☆ | • • SPACER ? 5.4MM | 1 | SN: K20001- |
|||
| ? | ☆ | • • SPACER ? 5.8MM | 1 | SN: K20001- |
|||
| ? | (★04064-04518) | • RING,SNAP | 1 | SN: K20001- |
|||
| ? | 706-75-42711 | • COVER | 1 | SN: K20001- |
|||
| ? | 706-7E-11280 | • SEAL,OIL | 1 | SN: K20001- |
|||
| ? | 07000-02085 | • O-RING | 1 | SN: K20001- |
|||
| ? | 04065-09030 | • RING,SNAP | 1 | SN: K20001- |
|||
| ? | (★706-75-92180) | • PISTON,BRAKE | 1 | SN: K20001- |
|||
| ? | (★07000-15155) | • O-RING | 1 | SN: K20001- |
|||
| ? | (★07000-15175) | • O-RING | 1 | SN: K20001- |
|||
| ? | (★07000-05200) | • O-RING | 1 | SN: K20001- |
|||
| ? | (★706-75-92140) | • PLATE | 5 | SN: K20001- |
|||
| ? | (★706-75-92150) | • DISK | 4 | SN: K20001- |
|||
| ? | (★706-75-92130) | • PLATE | 1 | SN: K20001- |
|||
| ? | (★706-87-50360) | • BOLT | 8 | SN: K20001- |
