| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (700-85-49001) | VALVE ASS'Y,R.H. | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6211 TO 6214. | ||||||
| ? | ☆ | • BLOCK,VALVE | 1 | SN: K20001- |
|||
| ? | ☆ | • BLOCK,VALVE | 1 | SN: K20001- |
|||
| ? | ☆ | • BODY,VALVE | 1 | SN: K20001- |
|||
| ? | 07000-03038 | • O-RING | 6 | SN: K20001- |
|||
| ? | 07000-13050 | • O-RING | 3 | SN: K20001- |
|||
| ? | 700-84-11330 | • BRACKET | 1 | SN: K20001- |
|||
| ? | 01010-51020 | • BOLT | 2 | SN: K20001- |
|||
| ? | 709-74-91860 | • PLUG | 1 | SN: K20001- |
|||
| ? | 07002-12434 | • O-RING | 1 | SN: K20001- |
|||
| ? | 07040-13316 | • PLUG | 1 | SN: K20001- |
|||
| ? | 07002-13334 | • O-RING | 1 | SN: K20001- |
|||
| ? | ☆ | • SPOOL,BUCKET | 1 | SN: K20001- |
|||
| ? | ☆ | • SPOOL,STRAIGHT TRAVEL | 1 | SN: K20001- |
|||
| ? | ☆ | • SPOOL,R.H. TRAVEL | 1 | SN: K20001- |
|||
| ? | 700-84-15740 | • SPRING | 2 | SN: K20001- |
|||
| ? | 700-84-13880 | • SPRING | 1 | SN: K20001- |
|||
| ? | 700-84-15710 | • SPRING | 1 | SN: K20001- |
|||
| ? | 700-84-13790 | • JOINT | 1 | SN: K20001- |
|||
| ? | 07002-11223 | • O-RING | 1 | SN: K20001- |
|||
| ? | 700-84-13781 | • RETAINER | 2 | SN: K20001- |
|||
| ? | 700-84-12510 | • CASE | 2 | SN: K20001- |
|||
| ? | 700-84-13490 | • PLATE | 1 | SN: K20001- |
|||
| ? | 700-84-11240 | • O-RING | 3 | SN: K20001- |
|||
| ? | 01252-30616 | • BOLT | 2 | SN: K20001- |
|||
| ? | 01252-30625 | • BOLT | 2 | SN: K20001- |
|||
| ? | 700-84-13870 | • PLUG | 1 | SN: K20001- |
|||
| ? | 07002-02434 | • O-RING | 1 | SN: K20001- |
|||
| ? | 700-84-13510 | • NIPPLE | 1 | SN: K20001- |
|||
| ? | 07000-12015 | • O-RING | 1 | SN: K20001- |
|||
| ? | 07002-02434 | • O-RING | 1 | SN: K20001- |
|||
| ? | 700-84-13711 | • RETAINER | 2 | SN: K20001- |
|||
| ? | 700-84-11641 | • COLLAR | 1 | SN: K20001- |
|||
| ? | 01252-30830 | • BOLT | 1 | SN: K20001- |
|||
| ? | 01643-30823 | • WASHER | 1 | SN: K20001- |
|||
| ? | 700-84-11390 | • COVER | 1 | SN: K20001- |
|||
| ? | 700-84-13891 | • PLATE | 2 | SN: K20001- |
|||
| ? | 700-84-13910 | • SEAL | 2 | SN: K20001- |
|||
| ? | 01252-30612 | • BOLT | 2 | SN: K20001- |
|||
| ? | 01252-30625 | • BOLT | 2 | SN: K20001- |
|||
| ? | 700-42-31460 | • VALVE | 1 | SN: K20001- |
|||
| ? | 700-42-31470 | • SPRING | 1 | SN: K20001- |
|||
| ? | 700-84-11320 | • PLUG | 2 | SN: K20001- |
|||
| ? | 07002-13034 | • O-RING | 2 | SN: K20001- |
|||
| ? | (709-70-74302) | • VALVE ASS'Y,SUCTION AND SAFETY | 2 | SN: K20001- |
|||
| ? | (709-80-52900) | • RELIEF VALVE ASS'Y,RELIEF | 1 | SN: K20001- |
|||
| ? | (709-20-81201) | • VALVE ASS'Y,SUCTION | 2 | SN: K20001- |
