| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-25-04032) | PUMP ASS'Y,HYDRAULIC (HPV71+71) | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 TO 6171. | ||||||
| ? | (708-25-06231) | • SERVO VALVE ASS'Y,SERVO ? REAR | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6141 TO 6152. | ||||||
| ? | 708-25-06631 | • • VALVE ASS'Y,C.O. AND N.C. | 1 | SN: K20001- |
|||
| ? | (★708-23-00430) | • • • BODY ASS'Y | 1 | SN: K20001- |
|||
| ? | ☆ | • • • • BODY | 1 | SN: K20001- |
|||
| ? | ☆ | • • • • EXPANDER | 16 | SN: K20001- |
|||
| ? | (★708-25-17460) | • • • PLUG | 1 | SN: K20001- |
|||
| ? | (★07000-02010) | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★708-25-17131) | • • • COVER | 1 | SN: K20001- |
|||
| ? | (★01580-10806) | • • • NUT | 1 | SN: K20001- |
|||
| ? | (★708-25-17141) | • • • SPOOL | 2 | SN: K20001- |
|||
| ? | (★708-25-17150) | • • • SLEEVE | 1 | SN: K20001- |
|||
| ? | (★708-25-17160) | • • • PISTON | 1 | SN: K20001- |
|||
| ? | (★708-25-17170) | • • • COVER | 1 | SN: K20001- |
|||
| ? | (★07000-02014) | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★708-25-17180) | • • • SEAT | 1 | SN: K20001- |
|||
| ? | (★708-25-17690) | • • • SPRING | 1 | SN: K20001- |
|||
| ? | (★708-25-17451) | • • • SLEEVE | 1 | SN: K20001- |
|||
| ? | (★07000-02012) | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★708-25-17220) | • • • PISTON | 1 | SN: K20001- |
|||
| ? | (★07000-12012) | • • • O-RING | 2 | SN: K20001- |
|||
| ? | (★07001-02012) | • • • RING,BACK-UP | 2 | SN: K20001- |
|||
| ? | (★708-25-17370) | • • • SEAT | 1 | SN: K20001- |
|||
| ? | (★708-25-17250) | • • • SPRING | 1 | SN: K20001- |
|||
| ? | (★708-25-17260) | • • • SEAT | 1 | SN: K20001- |
|||
| ? | (★708-23-17240) | • • • COVER | 1 | SN: K20001- |
|||
| ? | (★708-25-17380) | • • • PLUG | 1 | SN: K20001- |
|||
| ? | (★07000-02021) | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★708-23-17270) | • • • PISTON | 1 | SN: K20001- |
|||
| ? | (★708-25-15320) | • • • BOLT | 2 | SN: K20001- |
|||
| ? | (★01602-20619) | • • • WASHER,SPRING | 2 | SN: K20001- |
|||
| ? | (★01580-10806) | • • • NUT | 1 | SN: K20001- |
|||
| ? | (★708-25-15320) | • • • BOLT | 6 | SN: K20001- |
|||
| ? | (★01602-20619) | • • • WASHER,SPRING | 6 | SN: K20001- |
|||
| ? | (★07000-12021) | • • • O-RING | 2 | SN: K20001- |
|||
| ? | (★07001-02021) | • • • RING,BACK-UP | 3 | SN: K20001- |
|||
| ? | 07040-11007 | • • • PLUG | 1 | SN: K20001- |
|||
| ? | 07002-01023 | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★708-25-17430) | • • • SCREW | 1 | SN: K20001- |
|||
| ? | (★708-25-15340) | • • • SCREW | 1 | SN: K20001- |
|||
| ? | (★708-23-17290) | • • • COVER | 1 | SN: K20001- |
|||
| ? | (★07000-03028) | • • • O-RING | 1 | SN: K20001- |
|||
| ? | (★706-75-40310) | • • • BOLT | 2 | SN: K20001- |
|||
| ? | (★01602-20619) | • • • WASHER,SPRING | 2 | SN: K20001- |
