| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-25-04032) | PUMP ASS'Y,HYDRAULIC (HPV71+71) | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 TO 6171. | ||||||
| ? | (708-25-04132) | • PUMP SUB ASS'Y,HYDRAULIC | 1 | SN: K20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6111 TO 6115. | ||||||
| ? | (★708-25-00410) | • • BLOCK ASS'Y,CYLINDER | 1 | SN: K20001- |
|||
| ? | (★708-25-13151) | • • • BLOCK,CYLINDER | 1 | SN: K20001- |
|||
| ? | (★708-25-13620) | • • • PLATE,VALVE | 1 | SN: K20001- |
|||
| ? | (★708-25-22722) | • • SHAFT,REAR | 1 | SN: K20001- |
|||
| ? | (★708-25-13422) | • • RETAINER,SHOE | 1 | SN: K20001- |
|||
| ? | (★708-25-13130) | • • SPRING | 1 | SN: K20001- |
|||
| ? | (★708-25-13120) | • • WASHER | 1 | SN: K20001- |
|||
| ? | (★708-25-13140) | • • RING,SNAP | 1 | SN: K20001- |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: K20001- |
|||
| ? | (★708-25-13312) | • • PISTON SUB ASS'Y | 9 | SN: K20001- |
|||
| ? | (★708-25-05061) | • • SPACER KIT | 1 | SN: K20001- |
|||
| ? | ☆ | • • • SPACER ? 11.540MM | 2 | SN: K20001- |
|||
| ? | ☆ | • • • SPACER ? 11.560MM | 2 | SN: K20001- |
|||
| ? | ☆ | • • • SPACER ? 11.575MM | 2 | SN: K20001- |
|||
| ? | (★708-25-13441) | • • RETAINER,BEARING | 2 | SN: K20001- |
|||
| ? | (★708-25-13470) | • • SCREW | 4 | SN: K20001- |
|||
| ? | (★01643-30623) | • • WASHER | 4 | SN: K20001- |
|||
| ? | (★708-25-14211) | • • PISTON | 1 | SN: K20001- |
|||
| ? | 708-25-14130 | • • SPRING | 1 | SN: K20001- |
|||
| ? | (★708-25-24110) | • • CAP | 1 | SN: K20001- |
|||
| ? | (★708-25-14150) | • • CAP | 1 | SN: K20001- |
|||
| ? | 07000-02065 | • • O-RING | 2 | SN: K20001- |
|||
| ? | (★708-25-05050) | • • SHIM KIT | 2 | SN: K20001- |
|||
| ? | ☆ | • • • SHIM ? 0.1MM | 4 | SN: K20001- |
|||
| ? | ☆ | • • • SHIM ? 0.1MM | 2 | SN: K20001- |
|||
| ? | ☆ | • • • SHIM ? 0.2MM | 2 | SN: K20001- |
|||
| ? | ☆ | • • • SHIM ? 0.5MM | 3 | SN: K20001- |
|||
| ? | 01016-31035 | • • BOLT | 8 | SN: K20001- |
|||
| ? | 01643-31032 | • • WASHER | 8 | SN: K20001- |
