| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 3F1050051 | OPERATOR'S SEAT STAND | 1 | SN: F1001- |
|||
| ? | 801920104 | NUT | 4 | SN: F1001- |
|||
| ? | 802170001 | WASHER | 4 | SN: F1001- |
|||
| ? | 816101094 | SLIDE RAIL KIT, L.H. | 1 | SN: F1001- |
|||
| ? | 816101093 | SLIDE RAIL KIT, R.H. | 1 | SN: F1001- |
|||
| ? | 3F1050600 | ROD | 1 | SN: F1001- |
|||
| ? | 3F1042613 | COVER | 1 | SN: F1001- |
|||
| ? | 816212952 | LOCK, ASSY. | 1 | SN: F1001- |
|||
| ? | 801250260 | SCREW | 3 | SN: F1001- |
|||
| ? | 801852206 | NUT | 3 | SN: F1001- |
|||
| ? | 816212687 | WASHER | 3 | SN: F1001- |
|||
| ? | 3F1042062 | HINGE | 1 | SN: F1001- |
|||
| ? | 801250059 | SCREW | 2 | SN: F1001- |
|||
| ? | 802120006 | SPRING WASHER | 2 | SN: F1001- |
|||
| ? | 855710069 | GASKET | 1 | SN: F1001- |
|||
| ? | 816100052 | OPERATOR'S SEAT, ASSY. | 1 | SN: F1001-F1256 |
A | ||
| ? | 816100053 | OPERATOR'S SEAT, ASSY. | 1 | SN: F1257- |
B | ||
| ? | 816101117 | • SEAT BACK | 1 | SN: F1001-F1256 |
A | ||
| ? | 816101134 | • SEAT BACK | 1 | SN: F1257- |
B | ||
| ? | 816101116 | • SEAT CUSHION | 1 | SN: F1001-F1256 |
A | ||
| ? | 816101133 | • SEAT CUSHION | 1 | SN: F1257- |
B | ||
| ? | 816101122 | • COVER | 1 | SN: F1001-F1256 |
A | ||
| ? | 816101139 | • PROTECTION | 1 | SN: F1257- |
B | ||
| ? | 816101119 | • DAMPER | 1 | SN: F1001-F1256 |
A | ||
| ? | 816101136 | • KIT, SPRING | 1 | SN: F1257- |
B | ||
| ? | 816101128 | • KIT, DRIVING SET | 1 | SN: F1001-F1256 |
A | ||
| ? | 816101135 | • KIT, DRIVING SET | 1 | SN: F1257- |
A | ||
| ? | 816210421 | • SEAT BELT | 1 | SN: F1001-F1256 |
|||
| ? | 801105531 | SCREW | 4 | SN: F1001- |
|||
| ? | 802170001 | WASHER | 4 | SN: F1001- |
|||
| ? | 801852212 | NUT | 1 | SN: F1001- |
|||
| ? | 390605069 | WASHER | 1 | SN: F1001- |
