| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (20W-60-R1500) | TRAVEL MOTOR | 1 | SN: F01425-F01554 |
|||
| ? | FUMVD20100P | • HUB, ASSY. | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • HUB | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PISTON | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • GASKET | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 1 | SN: F01425-F01554 |
|||
| ? | FUMVN101037 | • SHAFT, ASSY. | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SHAFT | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • BEARING | 1 | SN: F01425-F01554 |
|||
| ? | FUMHCB14841 | • CYLINDER, ASSY | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • CYLINDER | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLATE | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PISTON | 7 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SLIDE | 7 | SN: F01425-F01554 |
|||
| ? | ☆ | • • HOLDER | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • HOLDER | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PIN | 3 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPRING | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SHIM | 2 | SN: F01425-F01554 |
|||
| ? | FURH28 | • • RING, SNAP | 1 | SN: F01425-F01554 |
|||
| ? | FUMV68101T43 | • PLATE | 1 | SN: F01425-F01554 |
|||
| ? | FUMHB1CB4841 | • HOUSING, ASSY | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • BEARING | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PIN | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • BODY | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • REGISTER VALVE | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPRING GUIDE | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 6 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPRING | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPRING | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • SPRING | 1 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • RING | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 8 | SN: F01425-F01554 |
|||
| ? | ☆ | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | FUROP1490 | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | FUROP1890 | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PLUG | 5 | SN: F01425-F01554 |
|||
| ? | ☆ | • • PIN | 2 | SN: F01425-F01554 |
|||
| ? | FUGHS007B14841 | • KIT, GASKET | 1 | SN: F01425-F01554 |
|||
| ? | FUROG10590 | • • O-RING | 1 | SN: F01425-F01554 |
|||
| ? | FUROP690 | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | ☆ | • • GASKET | 1 | SN: F01425-F01554 |
|||
| ? | FUROG9590 | • • O-RING | 1 | SN: F01425-F01554 |
|||
| ? | FUROG9090 | • • O-RING | 1 | SN: F01425-F01554 |
|||
| ? | FURB0G95 | • • O-RING | 1 | SN: F01425-F01554 |
|||
| ? | FURB0G90 | • • O-RING | 1 | SN: F01425-F01554 |
|||
| ? | FUROP1490 | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | FUROP1890 | • • O-RING | 2 | SN: F01425-F01554 |
|||
| ? | FUYB15/32 | BALL | 2 | SN: F01425-F01554 |
|||
| ? | FUTH8X20 | SCREW | 7 | SN: F01425-F01554 |
|||
| ? | FUPPH76X14 | PIN | 1 | SN: F01425-F01554 |
|||
| ? | FUFZS2082282 | PISTON | 1 | SN: F01425-F01554 |
|||
| ? | FUFZS2082291 | SPRING | 14 | SN: F01425-F01554 |
|||
| ? | FUFZD4679136 | DISK | 1 | SN: F01425-F01554 |
|||
| ? | FUFZS2082372 | DISK | 1 | SN: F01425-F01554 |
