| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 22B-60-22110 | Motor Assembly | 2 | SN: C30001- |
|||
| ? | TZ600D200001-B | • Motor | 1 | SN: C30001- |
|||
| ? | TZ600D2205-01 | • • Cylinder, And Piston Kit | 1 | SN: C30001- |
|||
| ? | ☆ | • • • Piston Kit | 1 | SN: C30001- |
|||
| ? | ☆ | • • • • Piston Assembly | 9 | SN: C30001- |
|||
| ? | ☆ | • • • • • Piston | 1 | SN: C30001- |
|||
| ? | ☆ | • • • • • Shoe | 1 | SN: C30001- |
|||
| ? | ☆ | • • • • • Cylinder Block | 1 | SN: C30001- |
|||
| ? | TZ600D2070-01 | • • Piston Assembly | 1 | SN: C30001- |
|||
| ? | ☆ | • • • Piston | 1 | SN: C30001- |
|||
| ? | ☆ | • • • Shoe | 1 | SN: C30001- |
|||
| ? | TZ600D2002-01 | • • Shaft | 1 | SN: C30001- |
|||
| ? | TZ600D200300-B | • • Swash Plate Assembly | 1 | SN: C30001- |
|||
| ? | TZ600D2007-01 | • • Retainer Assembly | 1 | SN: C30001- |
|||
| ? | TZ600D2008-00 | • • Ball | 1 | SN: C30001- |
|||
| ? | TZ600D2009-01 | • • Plate | 1 | SN: C30001- |
|||
| ? | TZ880A2010-00 | • • Washer | 2 | SN: C30001- |
|||
| ? | TZ600D2012-00 | • • Piston | 1 | SN: C30001- |
|||
| ? | TZ500D2013-00 | • • Spring | 10 | SN: C30001- |
|||
| ? | TZ600D2014-00 | • • Spring | 1 | SN: C30001- |
|||
| ? | TZ600D2015-00 | • • Plate | 3 | SN: C30001- |
|||
| ? | TZ600D2016-00 | • • Plate | 4 | SN: C30001- |
|||
| ? | TZTCZ284810113 | • • Seal, Oil | 1 | SN: C30001- |
|||
| ? | TZ500D2039-00 | • • O-Ring | 1 | SN: C30001- |
|||
| ? | TZ600D2039-00 | • • O-Ring | 1 | SN: C30001- |
|||
| ? | TZTH-R-42 | • • Ring, Snap | 1 | SN: C30001- |
|||
| ? | TZJB1521-63-28 | • • Bearing | 1 | SN: C30001- |
|||
| ? | 06000-06304 | • • Bearing | 1 | SN: C30001- |
|||
| ? | TZJB15063-258F | • • Roller | 3 | SN: C30001- |
|||
| ? | TZ600D2076-01 | • • Pivot | 2 | SN: C30001- |
|||
| ? | TZ263B2077-01 | • • Pin | 2 | SN: C30001- |
|||
| ? | TZ600D2090-00 | • • Spring | 1 | SN: C30001- |
