| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 206-04-K1116 | Pump | 1 | SN: K50487- KIT-FLAG: _- SCC: SERIALNO: K50487- |
|||
| ? | 206-04-K1113 | Pump | 1 | SN: K50001-K50486 KIT-FLAG: _- SCC: A2 SERIALNO: K50001-K50486 |
|||
| ? | 20Y-04-K2451 | Valve Assembly | 1 | SN: K50489- KIT-FLAG: _- SCC: SERIALNO: K50489- |
|||
| ? | 20Y-04-K2450 | Valve Assembly | 1 | SN: K50001-K50488 KIT-FLAG: _- SCC: B1 SERIALNO: K50001-K50488 |
|||
| ? | 20Y-04-K2351 | Hose | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-04-K1121 | Hose | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 206-04-K1131 | Hose | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01010-81225 | Bolt | 4 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01643-31232 | Washer | 4 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-04-73150 | Tube | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07289-00035 | Clamp, Hose | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07289-00035 | Clamp, Hose | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07289-00035 | Clamp, Hose | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-04-38170 | Bracket | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01010-81025 | Bolt | 3 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01643-31032 | Washer | 3 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-04-72160 | Clamp | 3 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01010-81240 | Bolt | 3 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01643-31232 | Washer | 3 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 08034-20536 | Band | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
