| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 21K-70-00921 | Arm Assembly | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | • Arm | 1 | SN: K50001- KIT-FLAG: _- SCC: C1 SERIALNO: K50001- |
||||
| ? | 21K-70-72C80 | • • Seat,Welded | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-970-3560 | • • Bracket,Welded | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-970-3570 | • • Bracket,Welded | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20J-70-12180 | • • Seat,Welded | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20J-47-11250 | • • Seat,Welded | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-72410 | • • Seat,Welded | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-72270 | • Bushing | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 205-70-73180 | • Bushing | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-72290 | • Bushing | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07020-00000 | Fitting, Grease | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07020-00900 | Fitting, Grease | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-70-23220 | Seal, Dust | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-70-23220 | Seal, Dust | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 07145-00080 | Seal, Dust | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 20Y-70-31161 | Pin | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 205-70-66581 | Plate | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01010-81230 | Bolt | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-71650 | Spacer, 1.0mm | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-71192 | Pin | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 205-70-66581 | Plate | 1 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01010-81230 | Bolt | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-71630 | Spacer, 1.0mm | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
|||
| ? | 21K-70-71640 | Spacer, 2.0mm | 2 | SN: K50001- KIT-FLAG: _- SCC: SERIALNO: K50001- |
