Содержание Excavators Komatsu PC190LC-8 S/N K50001-UP(0000235U)
Boom, 2-Piece Boom, 1-Attachment, 1St Boom(T002001 : T1110-008001)
Номер на схеме Каталожный номер Название Количество Детали
? 21K-966-K773 Boom 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? • Boom 1
SN: K50001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K50001-
? 21K-966-K330 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K850 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K340 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K351 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K360 • • Bracket,Welded 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K371 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K380 • • Bracket,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 20Y-966-K450 • • Bracket,Welded 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-966-K820 • • Plate,Welded 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 20Y-966-K551 • • Plate,Welded 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-70-71311 • Bushing 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 07145-00080 • Seal, Dust 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 21K-70-K1210 Pin 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 207-70-73261 Spacer 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 207-70-73271 Spacer 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 205-70-66580 Plate 1
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 01010-81230 Bolt 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-
? 01643-31232 Washer 2
SN: K50001-
KIT-FLAG: _-
SCC:
SERIALNO: K50001-

Excavators Komatsu / PC190LC-8 S/N K50001-UP(0000235U) / Boom, 2-Piece Boom, 1-Attachment, 1St Boom(T002001 : T1110-008001)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
