| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6261-31-2130 | Piston | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6211-31-2410 | Pin, Piston | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 04065-05220 | Ring, Snap | 12 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6261-31-2040 | Ring Assembly, PER Cylinder | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | • Ring,Top | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Ring, Second | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Ring, Oil | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | 6261-31-3100 | Connecting Rod Assembly | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | • Rod | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Cap, Connecting Rod | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | 6261-31-3130 | • Bushing | 1 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-31-3310 | • Bolt | 2 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 02400-10413 | • Pin, Dowel | 2 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-32-3040 | Metal Assembly, Standard | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-39-3040 | Metal Assembly, Undersize 0.25mm | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-38-3040 | Metal Assembly, Undersize 0.50mm | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-37-3040 | Metal Assembly, Undersize 0.75mm | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | 6210-36-3040 | Metal Assembly, Undersize 1.00mm | 6 | SN: 536267- KIT-FLAG: _- SCC: SERIALNO: 536267- |
|||
| ? | • Metal, Lower | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Lower, Undersize 0.25mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Lower, Undersize 0.50mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Lower, Undersize 0.75mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Lower, Undersize 1.00mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Upper | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Upper, Undersize 0.25mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Upper, Undersize 0.50mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Upper, Undersize 0.75mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
||||
| ? | • Metal, Upper, Undersize 1.00mm | 1 | SN: 536267- KIT-FLAG: _- SCC: C1 SERIALNO: 536267- |
