| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37C-06-11321 | WIRING HARNESS, FRAME LINE, STANDARD | 1 | SN: F00003- |
A | ||
| ? | 37C-06-11331 | WIRING HARNESS, FRAME LINE, OPTIONAL | 1 | SN: F00003- |
B | ||
| ? | 37A-06-11160 | BRACKET | 1 | SN: F00003- |
|||
| ? | 01016-50825 | BOLT | 1 | SN: F00003- |
|||
| ? | 01643-10823 | WASHER | 1 | SN: F00003- |
|||
| ? | 37A-06-11171 | BRACKET | 1 | SN: F00003- |
|||
| ? | 04434-52310 | CLAMP | 1 | SN: F00003- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: F00003- |
|||
| ? | 01643-11032 | WASHER | 1 | SN: F00003- |
|||
| ? | 04434-51610 | CLAMP | 1 | SN: F00003- |
|||
| ? | 21D-09-24180 | NUT | 1 | SN: F00003- |
|||
| ? | 01643-10823 | WASHER | 1 | SN: F00003- |
|||
| ? | 08034-20519 | CLAMP | 9 | SN: F00003- |
|||
| ? | 37C-06-11312 | WIRING HARNESS, ENGINE LINE | 1 | SN: F00003- |
|||
| ? | 37A-06-12820 | • PLATE | 1 | SN: F00003- |
|||
| ? | 22E-06-11551 | • COVER | 1 | SN: F00003- |
|||
| ? | 226-06-11330 | • KNOB | 1 | SN: F00003- |
|||
| ? | 226-06-11350 | • RELAY | 1 | SN: F00003- |
|||
| ? | YM129211-77920 | • TIMER | 1 | SN: F00003- |
|||
| ? | YM119802-77200 | • RELAY | 1 | SN: F00003- |
|||
| ? | SEE FIG. 6555 | 6555 |
