Номер на схеме	Каталожный номер	Название	Количество	Детали
?	37A-54-14291	PANEL CONTROL	1	SN: F00003-
?	37A-54-14280	BRACKET	4	SN: F00003-
?	37A-09-39406	NUT	4	SN: F00003-
?	37A-54-14230	PANEL	1	SN: F00003-
?	37A-54-14240	PANEL	1	SN: F00003-
?	01225-40620	SCREW	2	SN: F00003-
?	37A-54-14340	PLUG	4	SN: F00003-
?	37A-54-14181	REAR PROTECTION	1	SN: F00003-
?	21D-09-24160	NUT	6	SN: F00003-
?	21U-54-31250	WASHER	6	SN: F00003-
?	21D-09-86180	PROTECTION	2	SN: F00003-
?	37A-06-11411	SWITCH, PARKING BRAKE	1	SN: F00003-
?	21D-06-12110	• BULB 1,2W 12V	1	SN: F00003-
?	37A-06-12340	SWITCH, ASSEMBLY	1	SN: F00003-
?	21D-06-12110	• BULB 1,2W 12V	1	SN: F00003-
?	885141236	LIGHT GLASS	1	SN: F00003-
?	22L-09-R1D90	PLUG	1	SN: F00003-
?	22E-06-12280	SWITCH, ASSEMBLY	1	SN: F00003-
?	21D-06-12110	• BULB 1,2W 12V	1	SN: F00003-
?	37A-06-12350	GLASS, ROTATING BEAM	1	SN: F00003-
?	21D-06-11780	FUSE BOX, ASSEMBLY	1	SN: F00003-
?	21D-06-11790	FUSE 3A	2	SN: F00003-		A
?	21D-06-11810	FUSE 7,5A	3	SN: F00003-		B
?	21D-06-11820	FUSE 10A	3	SN: F00003-		C
?	21D-06-11830	FUSE 15A	2	SN: F00003-		D
?	22L-09-R2T60	• FUSE 20A	1	SN: F00003-		E
?	22L-09-R2T50	FUSE 30A	1	SN: F00003-		F
?	21D-09-16110	SCREW	2	SN: F00003-
?	21D-54-11460	WASHER	2	SN: F00003-
?	20S-06-31130	STARTING BLOCK	1	SN: F00003-
?	22E-06-11830	BUZZER	1	SN: F00003-
?	01643-10623	WASHER	4	SN: F00003-
?	21U-54-31250	WASHER	4	SN: F00003-
?	37A-06-11760	PUSH-BUTTON	1	SN: F00003-
?	21D-06-12110	• BULB 1,2W 12V	1	SN: F00003-
?	37A-98-11520	MARK PLATE, RIDE CONTROL	1	SN: F00003-
?	37A-06-11880	WIRING HARNESS, RIDE CONTROL LINE	1	SN: F00003-
?		SEE FIG. 1500			1500
