| Наименование | Страница | Код страницы |
|---|---|---|
| HYDRAULIC PUMP (STANDARD) (1/13) | F-6100 | 6100 |
| HYDRAULIC PUMP (HIGH-FLOW) (1/13) | F-6150 | 6150 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37C-01-12240 | COUPLING | 1 | SN: F00003- |
|||
| ? | 01016-51030 | BOLT | 8 | SN: F00003- |
|||
| ? | 01643-11032 | WASHER | 20 | SN: F00003- |
|||
| ? | 37C-01-11510 | COVER | 1 | SN: F00003- |
|||
| ? | 01010-81025 | BOLT | 12 | SN: F00003- |
|||
| ? | (720-2T-00160) | HYDRAULIC PUMP ASSEMBLY (STANDARD) | 1 | SN: F00003- |
6100 | A | |
| ? | (720-2T-00150) | HYDRAULIC PUMP ASSEMBLY (HIGH FLOW) | 1 | SN: F00003- |
6150 | B | |
| ? | 01252-71460 | BOLT, HEXAGON SOCKET HEAD | 2 | SN: F00003- |
|||
| ? | 01643-11445 | WASHER | 2 | SN: F00003- |
|||
| ? | 21D-09-73230 | WASHER | 2 | SN: F00003- |
|||
| ? | 37C-01-11170 | HOSE | 1 | SN: F00003- |
|||
| ? | 21D-09-61160 | PLUG | 1 | SN: F00003- |
|||
| ? | 37A-01-11170 | UNION | 1 | SN: F00003- |
|||
| ? | 22L-62-24670 | SEAL | 1 | SN: F00003- |
|||
| ? | 21D-01-11160 | VALVE | 1 | SN: F00003- |
|||
| ? | 21D-01-11170 | UNION | 1 | SN: F00003- |
