| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 42N-856-1611 | JIG ARM - FIXED PART ASSEMBLY | 1 | SN: F80211-F80300 |
A | ||
| ? | 42N-856-1612 | JIG ARM - FIXED PART ASSEMBLY | 1 | SN: F80301- |
B | ||
| ? | 37B-09-46039 | PIN | 1 | SN: F80211- |
|||
| ? | 01011-81010 | BOLT | 1 | SN: F80211- |
|||
| ? | 21D-09-24190 | NUT | 1 | SN: F80211- |
|||
| ? | 42N-856-3320 | PIN | 1 | SN: F80211- |
|||
| ? | 21D-09-72510 | WASHER | 1 | SN: F80211- |
|||
| ? | 21D-09-85530 | PIN, SNAP | 1 | SN: F80211- |
|||
| ? | 42N-856-3330 | SCREW | 8 | SN: F80211- |
|||
| ? | 01640-21826 | WASHER | 16 | SN: F80211- |
|||
| ? | 01580-11815 | NUT | 8 | SN: F80211- |
|||
| ? | 42N-856-2840 | SHOE | 4 | SN: F80211- |
|||
| ? | 01016-51040 | BOLT | 8 | SN: F80211- |
|||
| ? | 01643-31032 | WASHER | 8 | SN: F80211- |
|||
| ? | 42N-856-1520 | SLIDE | 4 | SN: F80211- |
|||
| ? | 42N-856-2830 | SPACER | 2 | SN: F80211- |
|||
| ? | 42N-856-1510 | JIG ARM - MOVABLE PART | 1 | SN: F80211- |
|||
| ? | 42N-856-1710 | PIN | 1 | SN: F80211- |
|||
| ? | 04064-04018 | SNAP, RING | 2 | SN: F80211- |
|||
| ? | 37B-09-4F024 | SHIM, 4.750 MM | 2 | SN: F80211- |
|||
| ? | 37B-09-54006 | BUSHING | 4 | SN: F80211- |
|||
| ? | 37B-09-4C064 | SPACER | 2 | SN: F80211- |
|||
| ? | 21D-09-89140 | FITTING, GREASE | 2 | SN: F80211- |
|||
| ? | 42N-856-3860 | SEAL | 1 | SN: F80211- |
