| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37B-98-11110 | MARK PLATE SK815 (L.H.) | 1 | SN: 37BTF00003- |
|||
| ? | 37B-98-11120 | MARK PLATE SK815 (R.H.) | 1 | SN: 37BTF00003- |
|||
| ? | 312614617 | PLATE, UTILITY | 2 | SN: 37BTF00003- |
|||
| ? | 37A-98-11140 | MARK PLATE KOMATSU | 2 | SN: 37BTF00003- |
|||
| ? | 37A-98-11150 | MARK PLATE KOMATSU | 1 | SN: 37BTF00003- |
|||
| ? | 3F10B2608 | PLATE, ANCHOR POINTS | 2 | SN: 37BTF00003- |
|||
| ? | 3F05B2608 | PLATE, LIFTING POINT | 4 | SN: 37BTF00003- |
|||
| ? | 37A-98-12140 | PLATE, SAFETY, HYDRAULIC OIL | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12370 | PLATE, HOT WATER HAZARD | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12330 | MARK PLATE, CALIFORNIA | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12160 | PLATE, AIR FILTER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12150 | PLATE, DO NOT USE ETHER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12320 | PLATE, SAFETY, ELECTRIC SOCKET | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12130 | PLATE, SAFETY, FUEL | 1 | SN: 37BTF00003- |
|||
| ? | 3F10B2610 | PLATE, SAFETY, EMERGENCY EXIT | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12280 | MARK PLATE, DOCUMENTATION BOX | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12360 | MARK PLATE, BRAKE CONTROL | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11961 | MARK PLATE, LUBRICATING TABLE | 1 | SN: 37BTF00003- |
|||
| ? | 312614600 | PLATE, FUEL CONTROL LEVER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11720 | MARK PLATE, 2 SPEED | 2 | SN: 37BTF00003- |
|||
| ? | 37A-98-11211 | MARK PLATE, TRAVEL SPEED INCREMENT | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11162 | MARK PLATE, FUSES DIAGRAM | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11171 | MARK PLATE, SAFETY BAR | 2 | SN: 37BTF00003- |
|||
| ? | 37A-98-12190 | MARK PLATE, HYDRAULIC OIL LEVEL | 1 | SN: 37BTF00003- |
|||
| ? | 37A-43-12231 | MARK PLATE, STARTER KEY | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11341 | MARK PLATE, CAB RETAINER | 1 | SN: 37BTF00003- |
|||
| ? | 09970-00230 | PLATE, GALEO | 1 | SN: 37BTF00003- |
|||
| ? | 37C-98-11211 | MARK PLATE, SAFETY | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11361 | MARK PLATE, SAFETY DOOR | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11271 | MARK PLATE, REMOVAL OF SAFETY BAR | 2 | SN: 37BTF00003- |
|||
| ? | 37A-98-12170 | MARK PLATE, ATTENTION ENGINE RUNNING | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12110 | MARK PLATE, DANGER PRESSURE | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12220 | MARK PLATE, CALIFORNIA BATTERY | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12120 | MARK PLATE, DANGER PINCH POINT | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-12180 | MARK PLATE, DANGER, GAS BATTERY | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11231 | MARK PLATE, TOOL BOX | 1 | SN: 37BTF00003- |
|||
| ? | 312614667 | PLATE, DO NOT OPERATE | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11370 | MARK PLATE, SAFETY ENGINE COVER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11471 | MARK PLATE, FLOATING FOR HAND&FOOT CONTROL | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11461 | MARK PLATE, CONTROL TABLE (HAND&FOOT CONTROL) | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11481 | MARK PLATE, BRAKING PEDAL, L.H. | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11491 | MARK PLATE, BRAKING PEDAL, R.H. | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11321 | PLATE, OPERATING, R.H. PPC VALVE | 1 | SN: 37BTF00003- |
|||
| ? | 37A-98-11640 | MARK PLATE, AUXILIARY HYDRAULIC KIT | 1 | SN: 37BTF00003- |
|||
| ? | 37B-98-11130 | MARK PLATE, TURBO | 2 | SN: 37BTF00003- |
