| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (720-2T-00025) | HYDRAULIC PUMP, ASSY. | 1 | SN: 37BF50003- |
|||
| ? | 07372-21030 | • BOLT | 2 | SN: 37BF50003- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 37BF50003- |
|||
| ? | 720-2T-19110 | • FLANGE | 1 | SN: 37BF50003- |
|||
| ? | 07000-12125 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 07000-12080 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 01252-61230 | • SCREW | 2 | SN: 37BF50003- |
|||
| ? | 720-2T-03720 | • PUMP, ASSY. | 1 | SN: 37BF50003- |
|||
| ? | SEE FIG. 6100 | 6100 | |||||
| ? | SEE FIG. 6108 | 6108 |
