| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37A-62-10020 | UNION | 2 | SN: 37BF50003- |
|||
| ? | 890001254 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 37B-62-15220 | HOSE | 2 | SN: 37BF50003- |
|||
| ? | 37B-970-1761 | PIPE | 1 | SN: 37BF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 37B-970-1771 | PIPE | 1 | SN: 37BF50003- |
|||
| ? | 855051015 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 200362282 | COUPLING, ASSY. | 1 | SN: 37BF50003- |
|||
| ? | 855051016 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 200362286 | COUPLING, ASSY. | 1 | SN: 37BF50003- |
|||
| ? | 855051016 | • O-RING | 1 | SN: 37BF50003- |
|||
| ? | 37A-970-1411 | SUPPORT | 1 | SN: 37BF50003- |
|||
| ? | 801015108 | BOLT | 2 | SN: 37BF50003- |
|||
| ? | 802170002 | WASHER | 2 | SN: 37BF50003- |
|||
| ? | 818000023 | CLAMP | 4 | SN: 37BF50003- |
|||
| ? | 801015552 | BOLT | 1 | SN: 37BF50003- |
|||
| ? | 802148009 | WASHER | 1 | SN: 37BF50003- |
|||
| ? | 37A-70-11410 | O-RING | 10 | SN: 37BF50003- |
|||
| ? | 818000024 | PLATE | 1 | SN: 37BF50003- |
|||
| ? | 37B-70-17340 | PLATE | 1 | SN: 37BF50003- |
|||
| ? | 801880208 | NUT | 1 | SN: 37BF50003- |
|||
| ? | 37B-70-17330 | CLAMP | 4 | SN: 37BF50003- |
|||
| ? | 801015548 | BOLT | 2 | SN: 37BF50003- |
|||
| ? | 802170001 | SPRING WASHER | 3 | SN: 37BF50003- |
|||
| ? | 500153465 | BRACKET | 1 | SN: 37BF50003- |
|||
| ? | 37A-70-11290 | SPACER | 1 | SN: 37BF50003- |
|||
| ? | 801015545 | BOLT | 1 | SN: 37BF50003- |
|||
| ? | SEE FIG. 6600 | 6600 |
