Содержание Skid Steer Loaders Komatsu SK818-5 S/N 37BF50111-Up(sk818_a)
MARK AND PLATES(H-9810 : 9810)
Номер на схеме Каталожный номер Название Количество Детали
? 37B-98-17111 MARK PLATE, SK818, L.H. 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37B-98-17121 MARK PLATE, SK818, R.H. 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 42N-93-11510 MARK PLATE, UTILITY 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 09690-P0560 DECAL, KOMATSU LOGO 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11150 MARK PLATE, KOMATSU 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 21D-98-11860 PLATE, ANCHOR POINT 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 22L-09-R4160 PLATE, LIFTING POINT 4
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12210 PLATE, HYDRAULIC OIL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12290 PLATE, HYDRAULIC OIL LEVEL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12310 PLATE, HYDRAULIC OIL FILTER 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12260 PLATE, ENGINE AIR FILTER 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12250 PLATE, FUEL FILTER 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12230 PLATE, ENGINE OIL FILTER 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12340 PLATE, COOLANT 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12270 PLATE, RADIATOR CAP 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12320 PLATE, ELECTRIC SOCKET 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12240 PLATE, FUEL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 22L-98-18270 PLATE, SAFETY EMERGENCY EXIT 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12350 PLATE, DO NOT OPEN ENGINE HOOD 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12280 PLATE, DOCUMENTATION BOX 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12360 PLATE, BRAKE CONTROL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 42N-93-11590 PLATE, LWA 104 1
SN: 37BF50111-37BF50177
 A
? 37A-98-12510 PLATE, LWA 101 1
SN: 37BF50178-37BF50333; 37BF50335-37BF50371
 B
? 37A-98-12540 PLATE, LPA 87 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37B-98-17131 PLATE, LUBRICATING TABLE 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 42N-93-11190 PLATE, FUEL LEVER 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11241 PLATE, CONTROL TABLE 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11211 PLATE, TRAVEL SPEED INCREMENT 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11163 PLATE, FUSES DIAGRAM 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37B-98-17151 PLATE, SAFETY BAR 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-12190 PLATE, HYDRAULIC OIL LEVEL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-43-12231 PLATE, STARTER KEY 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11351 PLATE, READ MANUAL 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 09970-00230 PLATE, GALEO 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11430 PLATE, MAX. SPEED 16 KM/H 3
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11380 PLATE, SAFETY LOCK 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11361 PLATE, SAFETY DOOR 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11130 PLATE, SUPER FLOW 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11720 PLATE, 2 SPEED 2
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
? 37A-98-11331 PLATE, HIGH FLOW 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
 A
? 37A-98-11311 PLATE, SUPER HIGH FLOW 1
SN: 37BF50111-37BF50333; 37BF50335-37BF50371
 B
