| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 845240010 | SOLENOID VALVE, ASSEMBLY | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | ☆ | • BODY | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 845241003 | • SOLENOID, ASSEMBLY | 3 | SN: 37BF50111-37BF50211 |
|||
| ? | 845241008 | • SCREW | 6 | SN: 37BF50111-37BF50211 |
|||
| ? | 01010-80675 | BOLT | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 01643-10623 | WASHER | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 3F1077059 | UNION | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37B-09-88004 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 855150038 | GASKET | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 847001011 | ACCUMULATOR | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-61270 | UNION | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-69960 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 42N-64-11350 | VALVE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 22L-62-24660 | GASKET | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-51180 | UNION | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-12211 | HOSE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 392368110 | HOSE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 22E-09-11610 | ELBOW | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37B-09-88006 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-57820 | TEE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-69960 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-52520 | TEE | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-55620 | ELBOW | 3 | SN: 37BF50111-37BF50211 |
|||
| ? | 22L-09-R3K70 | UNION | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-69960 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-14111 | HOSE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-14141 | HOSE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-14350 | HOSE | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-14520 | UNION | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 855021111 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-06-11670 | PRESSURE SWITCH | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 200343220 | PLUG | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-51620 | ELBOW | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-69960 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | 37A-62-13340 | UNION | 2 | SN: 37BF50111-37BF50211 |
|||
| ? | 21D-09-69960 | • O-RING | 1 | SN: 37BF50111-37BF50211 |
|||
| ? | SEE FIG. 6550 | 6550 | |||||
| ? | SEE FIG. 6660 | 6660 |
