| Наименование | Страница | Код страницы |
|---|---|---|
| TRAVEL MOTOR (1/4) | F-6430 | 6430 |
| TRAVEL MOTOR (2/4) | F-6433 | 6433 |
| TRAVEL MOTOR (3/4) | F-6435 | 6435 |
| TRAVEL MOTOR (3/4) | F-6435 | 6435 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37A-60-11102) | TRAVEL MOTOR, ASSEMBLY | 2 | SN: 37BF50111- |
6430 | ||
| ? | (FUPMV2B4528B2A) | • HYDRAULIC MOTOR, ASSEMBLY | 1 | SN: 37BF50111- |
6433 | ||
| ? | (FUZZT04A8957A) | • • DOUBLE SHOCK VALVE | 1 | SN: 37BF50111- |
6435 | ||
| ? | FUZR01A8957A | • • • VALVE, RELIEF | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • RETAINER | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • POPPET | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • SPRING, GUIDE | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • SPRING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • ADJUSTER KIT | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | (FUMHV-5-8957) | • • • • SEAL KIT | 1 | SN: 37BF50111- |
6435 | ||
| ? | ☆ | • • • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • • • O-RING | 1 | SN: 37BF50111- |
