| Наименование | Страница | Код страницы |
|---|---|---|
| TRAVEL MOTOR (1/4) | F-6430 | 6430 |
| TRAVEL MOTOR (3/4) | F-6435 | 6435 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37A-60-11102) | TRAVEL MOTOR, ASSEMBLY | 2 | SN: 37BF50111- |
6430 | ||
| ? | FUPMV2B4528B2A | • HYDRAULIC MOTOR, ASSEMBLY | 1 | SN: 37BF50111- |
|||
| ? | FUMHB-1-4860 | • • BODY KIT, SUBASSEMBLY | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • BODY | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • BEARING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • PIN, SPRING | 1 | SN: 37BF50111- |
|||
| ? | FUMHCB-1-4860 | • • CYLINDER BARREL, ASSEMBLY | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • CYLINDER BARREL | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • VALVE PLATE | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • PISTON | 9 | SN: 37BF50111- |
|||
| ? | ☆ | • • • SHOE | 9 | SN: 37BF50111- |
|||
| ? | ☆ | • • • SHOE HOLDER | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • BARREL HOLDER | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • PIN | 3 | SN: 37BF50111- |
|||
| ? | ☆ | • • • SPRING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • RETAINER | 2 | SN: 37BF50111- |
|||
| ? | ☆ | • • • RING, SNAP | 1 | SN: 37BF50111- |
|||
| ? | FUMHSH-1-4860 | • • SHAFT, SUBASSEMBLY | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • SHAFT | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • BEARING | 1 | SN: 37BF50111- |
|||
| ? | FUMHS-1-4860 | • • SEAL KIT | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 37BF50111- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 37BF50111- |
|||
| ? | FUFZD4860602 | • • BODY | 1 | SN: 37BF50111- |
|||
| ? | FUFZD486041045 | • • SWASH PLATE | 1 | SN: 37BF50111- |
|||
| ? | FUFZD4860411 | • • CONTROL PISTON | 1 | SN: 37BF50111- |
|||
| ? | FUFZD4860426 | • • DISK PLATE | 1 | SN: 37BF50111- |
|||
| ? | FUFZD4363127 | • • PLATE, STEEL | 2 | SN: 37BF50111- |
|||
| ? | FUFZD4860417 | • • BRAKE PISTON | 1 | SN: 37BF50111- |
|||
| ? | FUFZD4860518 | • • SPACER | 1 | SN: 37BF50111- |
|||
| ? | FUFZS2808321 | • • SPRING | 24 | SN: 37BF50111- |
|||
| ? | FUGPF-1/2 | • • PLUG | 1 | SN: 37BF50111- |
|||
| ? | FUYB-3/4 | • • BALL | 2 | SN: 37BF50111- |
|||
| ? | FUPP-H7-8X15 | • • PIN | 2 | SN: 37BF50111- |
|||
| ? | FUTH-10X30 | • • BOLT | 9 | SN: 37BF50111- |
|||
| ? | FUFZD4860436 | • • SPRING | 1 | SN: 37BF50111- |
|||
| ? | (FUZZT04A8957A) | • • DOUBLE SHOCK VALVE | 1 | SN: 37BF50111- |
6435 | ||
| ? | FUTH-8X35 | • • BOLT | 2 | SN: 37BF50111- |
|||
| ? | FUTH-8X65 | • • BOLT | 2 | SN: 37BF50111- |
