| Наименование | Страница | Код страницы |
|---|---|---|
| CONTROL VALVE (SUPER HIGH FLOW) (1/13) | F-6360 | 6360 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-14-13100) | CONTROL VALVE (SUPER HIGH FLOW) | 1 | SN: 37BF50221- |
6360 | ||
| ? | ☆ | • SPOOL | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • SPOOL | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • PLUG | 1 | SN: 37BF50221- |
|||
| ? | 07002-10823 | • O-RING | 4 | SN: 37BF50221- |
|||
| ? | ☆ | • PLUG | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • PLUG | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • SPOOL | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • PISTON | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • GASKET | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • SPRING | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • POPPET | 1 | SN: 37BF50221- |
|||
| ? | ☆ | • SPRING | 1 | SN: 37BF50221- |
|||
| ? | 723-11-27470 | • SEAT, NOZZLE SPRING | 1 | SN: 37BF50221- |
|||
| ? | 723-11-28591 | • SPRING | 1 | SN: 37BF50221- |
|||
| ? | 723-11-17353 | • RETAINER | 1 | SN: 37BF50221- |
|||
| ? | 723-11-17361 | • BOLT | 1 | SN: 37BF50221- |
|||
| ? | 723-11-27181 | • SEAT, NOZZLE SPRING | 2 | SN: 37BF50221- |
|||
| ? | 723-11-27191 | • SEAT, NOZZLE SPRING | 2 | SN: 37BF50221- |
|||
| ? | 723-11-28431 | • SPRING | 2 | SN: 37BF50221- |
|||
| ? | 723-11-28440 | • SPRING | 2 | SN: 37BF50221- |
|||
| ? | 723-11-17470 | • PLUG | 1 | SN: 37BF50221- |
