| Наименование | Страница | Код страницы |
|---|---|---|
| CONTROL VALVE (HIGH FLOW) (1/11) | F-6300 | 6300 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-13-12900) | CONTROL VALVE (HIGH FLOW) | 1 | SN: 37BF50111-37BF50220 |
6300 | ||
| ? | 723-11-01153 | • CASE, ASSEMBLY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • BODY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • ORIFICE DISK | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-18820 | • • PLUG | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07002-11023 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SEAT | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • BALL | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SEAT | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 722-12-19120 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • PLUG | 3 | SN: 37BF50111-37BF50220 |
A | ||
| ? | 702-21-54260 | • • O-RING | 3 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • ORIFICE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-01390 | • CASE, ASSEMBLY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • BODY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SEAT | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • BALL | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SEAT | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 722-11-19120 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-27490 | • • PLATE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-18150 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • PISTON | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • PLUG | 3 | SN: 37BF50111-37BF50220 |
|||
| ? | 702-21-54260 | • • O-RING | 2 | SN: 37BF50111-37BF50220 |
|||
| ? | 702-16-53920 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
