| Наименование | Страница | Код страницы |
|---|---|---|
| CONTROL VALVE (HIGH FLOW) (1/11) | F-6300 | 6300 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-13-12900) | CONTROL VALVE (HIGH FLOW) | 1 | SN: 37BF50111-37BF50220 |
6300 | ||
| ? | ☆ | • SPOOL | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • PISTON | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-28530 | • RETAINER | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-28540 | • SPRING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • VALVE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-28551 | • SPRING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-27720 | • SEAT, NOZZLE SPRING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-29380 | • PLATE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 722-12-19120 | • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-29390 | • O-RING | 2 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-18150 | • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07000-11007 | • O-RING | 2 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-11-17450 | • PLUG | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07002-10823 | • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 01252-60620 | • BOLT | 5 | SN: 37BF50111-37BF50220 |
|||
| ? | 01252-60625 | • BOLT, HEXAGON SOCKET HEAD | 7 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • GASKET | 1 | SN: 37BF50111-37BF50220 |
