| Наименование | Страница | Код страницы |
|---|---|---|
| CONTROL VALVE (FLOAT) (1/11) | F-6260 | 6260 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-13-12800) | CONTROL VALVE (FLOATING) | 1 | SN: 37BF50111-37BF50220 |
6260 | ||
| ? | 723-11-19620 | • PLUG | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 709-32-11840 | • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07002-12034 | • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-10-80200 | • VALVE, ASSEMBLY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • VALVE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • GASKET | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 723-10-18600 | • VALVE, ASSEMBLY | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SLEEVE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • ORIFICE DISK | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SCREW | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07000-12011 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 01583-11408 | • • NUT | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 700-22-11410 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | 07002-12434 | • • O-RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • RING | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • VALVE | 1 | SN: 37BF50111-37BF50220 |
|||
| ? | ☆ | • • SPRING | 1 | SN: 37BF50111-37BF50220 |
