| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 816100057 | OPERATOR'S SEAT, ASSY. | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • GUIDE, R.H. | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • GUIDE, L.H. | 1 | SN: 37BTF50003- |
|||
| ? | 801015087 | BOLT | 4 | SN: 37BTF50003- |
|||
| ? | 802170001 | SPRING WASHER | 8 | SN: 37BTF50003- |
|||
| ? | 801880208 | NUT | 4 | SN: 37BTF50003- |
|||
| ? | 816215074 | 2'' SEAT BELT, ASSY. (OPTIONAL) | 1 | SN: 37BTF50003- |
A | ||
| ? | 816215075 | 3'' SEAT BELT, ASSY. (OPTIONAL) | 1 | SN: 37BTF50003- |
B | ||
| ? | 801015113 | BOLT | 3 | SN: 37BTF50003- |
|||
| ? | 802170002 | WASHER | 7 | SN: 37BTF50003- |
|||
| ? | 37A-57-11120 | SUPPORT | 2 | SN: 37BTF50003- |
|||
| ? | 801015111 | BOLT | 2 | SN: 37BTF50003- |
|||
| ? | 801880001 | NUT | 2 | SN: 37BTF50003- |
|||
| ? | 885201123 | CONNECTOR | 1 | SN: 37BTF50003- |
|||
| ? | 885201124 | PLATE | 1 | SN: 37BTF50003- |
|||
| ? | 885201114 | PIN | 2 | SN: 37BTF50003- |
