| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37C-04-11290 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 802660612 | CLAMP | 3 | SN: 37BTF50003- |
|||
| ? | 3F0513601 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 3F0513605 | PROTECTION | 1 | SN: 37BTF50003- |
|||
| ? | 3F0513602 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 3F0513604 | PROTECTION | 1 | SN: 37BTF50003- |
|||
| ? | 3F0535723 | SPRING | 1 | SN: 37BTF50003- |
|||
| ? | 801250056 | SCREW | 2 | SN: 37BTF50003- |
|||
| ? | 802130006 | WASHER | 2 | SN: 37BTF50003- |
|||
| ? | 801015062 | BOLT | 2 | SN: 37BTF50003- |
|||
| ? | 802150506 | SPRING WASHER | 2 | SN: 37BTF50003- |
|||
| ? | 802660628 | COLLAR | 1 | SN: 37BTF50003- |
|||
| ? | 801015552 | BOLT | 1 | SN: 37BTF50003- |
|||
| ? | 801015089 | BOLT | 1 | SN: 37BTF50003- |
|||
| ? | 885190007 | CLAMP | 1 | SN: 37BTF50003- |
|||
| ? | 802170001 | SPRING WASHER | 4 | SN: 37BTF50003- |
|||
| ? | SEE FIG. 0410 | 0410 | |||||
| ? | SEE FIG. 1300 | 1300 | |||||
| ? | SEE FIG. 4000 | 4000 |
