| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 500380872 | UNION TEE | 2 | SN: 37BTF50003- |
|||
| ? | 855051014 | • O-RING | 2 | SN: 37BTF50003- |
|||
| ? | 37A-62-15820 | HOSE | 2 | SN: 37BTF50003- |
|||
| ? | 500380137 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051113 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 500380537 | ELBOW | 1 | SN: 37BTF50003- |
|||
| ? | 855051113 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-15840 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051217 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 500351764 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051113 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-14730 | SOLENOID VALVE | 1 | SN: 37BTF50003- |
|||
| ? | 845241031 | • HOLDER, VALVE W/CASE | 1 | SN: 37BTF50003- |
|||
| ? | 845241029 | • VALVE | 2 | SN: 37BTF50003- |
|||
| ? | 845241033 | • KIT, GASKET | 1 | SN: 37BTF50003- |
|||
| ? | 845241030 | • COIL | 2 | SN: 37BTF50003- |
|||
| ? | 845241028 | • VALVE | 1 | SN: 37BTF50003- |
|||
| ? | 845241032 | • KIT, GASKET | 1 | SN: 37BTF50003- |
|||
| ? | 801015562 | BOLT | 2 | SN: 37BTF50003- |
|||
| ? | 802148013 | WASHER | 2 | SN: 37BTF50003- |
|||
| ? | 802170002 | WASHER | 2 | SN: 37BTF50003- |
|||
| ? | 847001020 | ACCUMULATOR | 1 | SN: 37BTF50003- |
|||
| ? | 500380584 | ELBOW | 1 | SN: 37BTF50003- |
|||
| ? | 855051616 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051014 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-06-11890 | SUPPORT | 1 | SN: 37BTF50003- |
|||
| ? | 500355331 | UNION TEE | 1 | SN: 37BTF50003- |
|||
| ? | 855051119 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 200343250 | PLUG | 1 | SN: 37BTF50003- |
|||
| ? | 885411265 | PRESSURE SWITCH | 1 | SN: 37BTF50003- |
|||
| ? | 334410611 | UNION TEE | 1 | SN: 37BTF50003- |
|||
| ? | 312614705 | MARK PLATE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-15850 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-15830 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-15810 | SUPPORT | 1 | SN: 37BTF50003- |
|||
| ? | 801015111 | BOLT | 2 | SN: 37BTF50003- |
|||
| ? | 801015086 | BOLT | 1 | SN: 37BTF50003- |
|||
| ? | 802170001 | SPRING WASHER | 1 | SN: 37BTF50003- |
|||
| ? | SEE FIG. 6520 | 6520 | |||||
| ? | SEE FIG. 6565 | 6565 | |||||
| ? | SEE FIG. 6600 | 6600 |
