| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 500352136 | ELBOW | 1 | SN: 37BTF50003- |
|||
| ? | 855051217 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-13190 | PIPE | 1 | SN: 37BTF50003- |
|||
| ? | 500352109 | ELBOW | 1 | SN: 37BTF50003- |
|||
| ? | 855051119 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-13410 | FILTER, ASSY. | 1 | SN: 37BTF50003- |
|||
| ? | 848100086 | • CARTRIDGE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-13420 | • OIL FILTER CLOGGING TRANSMITTER | 1 | SN: 37BTF50003- |
|||
| ? | 801015108 | BOLT | 4 | SN: 37BTF50003- |
|||
| ? | 802170002 | WASHER | 4 | SN: 37BTF50003- |
|||
| ? | 500351720 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051119 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-13124 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 500351741 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051217 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-12122 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | SEE FIG. 1200 | 1200 | |||||
| ? | SEE FIG. 6500 | 6500 | |||||
| ? | SEE FIG. 6520 | 6520 |
