| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-13-12700) | CONTROL VALVE, ASSY. | 1 | SN: 37BTF50003- |
A | ||
| ? | (723-13-12800) | CONTROL VALVE, ASSY. (FLOATING VERSION) | 1 | SN: 37BTF50003- |
B | ||
| ? | 801015090 | BOLT | 3 | SN: 37BTF50003- |
|||
| ? | 802170001 | SPRING WASHER | 3 | SN: 37BTF50003- |
|||
| ? | 37A-60-11240 | SPACER | 3 | SN: 37BTF50003- |
|||
| ? | 37A-60-11211 | SUPPORT | 1 | SN: 37BTF50003- |
|||
| ? | 801015108 | BOLT | 4 | SN: 37BTF50003- |
|||
| ? | 802170002 | WASHER | 6 | SN: 37BTF50003- |
|||
| ? | 37A-62-12132 | SUCTION BLOCK | 1 | SN: 37BTF50003- |
|||
| ? | 801015564 | BOLT | 2 | SN: 37BTF50003- |
|||
| ? | 37A-62-12142 | SLEEVE | 1 | SN: 37BTF50003- |
|||
| ? | 802660007 | CLAMP | 2 | SN: 37BTF50003- |
|||
| ? | 802660012 | CLAMP | 2 | SN: 37BTF50003- |
|||
| ? | 37A-62-10091 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855670017 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051018 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-10150 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051211 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 855051018 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-12221 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-10180 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855670034 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 500352106 | ELBOW | 1 | SN: 37BTF50003- |
|||
| ? | 855051217 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-12152 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-10170 | TEE | 1 | SN: 37BTF50003- |
|||
| ? | 855670034 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 500351741 | UNION | 1 | SN: 37BTF50003- |
|||
| ? | 855051217 | • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 37A-62-12113 | HOSE | 1 | SN: 37BTF50003- |
|||
| ? | 37A-60-11250 | GASKET | 1 | SN: 37BTF50003- |
