| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-13-12700) | CONTROL VALVE, ASSY. | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-01171 | • VALVE, ASSY. | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • BODY | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-17360 | • • BOLT | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-17351 | • • SEAT, NOZZLE SPRING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-28690 | • • SPRING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-17410 | • • COVER | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-27520 | • • PLATE | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-17370 | • • COVER | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-17431 | • • RETAINER | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-27690 | • • SEAT, NOZZLE SPRING | 1 | SN: 37BTF50003- |
|||
| ? | 722-12-19120 | • • O-RING | 3 | SN: 37BTF50003- |
|||
| ? | 01252-60620 | • • SCREW | 2 | SN: 37BTF50003- |
|||
| ? | 01252-60650 | • • SCREW | 2 | SN: 37BTF50003- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-16230 | • • SPRING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-15130 | • • SPRING | 1 | SN: 37BTF50003- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-15110 | • • PLUG | 2 | SN: 37BTF50003- |
|||
| ? | 07002-11623 | • • O-RING | 2 | SN: 37BTF50003- |
|||
| ? | 07000-12100 | • • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-19110 | • • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-19150 | • • RING | 1 | SN: 37BTF50003- |
|||
| ? | 07000-11007 | • • O-RING | 1 | SN: 37BTF50003- |
|||
| ? | 723-11-19620 | • • PLUG | 2 | SN: 37BTF50003- |
|||
| ? | 07002-12034 | • • O-RING | 2 | SN: 37BTF50003- |
|||
| ? | 709-32-11840 | • • O-RING | 2 | SN: 37BTF50003- |
|||
| ? | SEE FIG. 6200 | 6200 |
