| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-7G-01130 | MOTOR ASSEMBLY | 1 | SN: K50001-K50283 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0. | ||||||
| ? | 706-7G-03090 | • MOTOR SUB ASSEMBLY | 1 | SN: K50001-K50283 |
|||
| ? | (★706-7G-41240) | • • CASE | 1 | SN: K50001-K50283 |
|||
| ? | (★706-7G-71141) | • • HOUSING | 1 | SN: K50001-K50283 |
|||
| ? | (★706-7G-40110) | • • BUSHING | 1 | SN: K50001-K50283 |
|||
| ? | (★708-8K-15190) | • • PIN, DOWEL | 1 | SN: K50001-K50283 |
|||
| ? | 709-25-11650 | • • VALVE, CHECK | 2 | SN: K50001-K50283 |
|||
| ? | 709-25-11361 | • • SPRING | 2 | SN: K50001-K50283 |
|||
| ? | 709-25-11640 | • • PLUG | 2 | SN: K50001-K50283 |
|||
| ? | 07000-12020 | • • O-RING | 2 | SN: K50001-K50283 |
|||
| ? | 708-21-12541 | • • PLUG | 3 | SN: K50001-K50283 |
|||
| ? | 708-8F-31620 | • • PLUG | 1 | SN: K50001-K50283 |
|||
| ? | 706-75-74540 | • • VALVE | 2 | SN: K50001-K50283 |
|||
| ? | 706-7G-71560 | • • SPRING | 2 | SN: K50001-K50283 |
|||
| ? | 706-7G-71620 | • • PLUG | 2 | SN: K50001-K50283 |
|||
| ? | 07002-13334 | • • O-RING | 2 | SN: K50001-K50283 |
|||
| ? | (★706-75-42370) | • • O-RING | 1 | SN: K50001-K50283 |
|||
| ? | 01010-61450 | • • BOLT | 6 | SN: K50001-K50283 |
