Содержание Excavators Komatsu PC240LC-8K S/N K50001-UP(pc240l3u)
DECAL AND PLATES (LC)(014001 : U0100-01A0)
Номер на схеме Каталожный номер Название Количество Детали
? 206-00-K2169 DECAL KIT 1
SN: K51118-
? 206-00-K2168 DECAL KIT 1
SN: K51094-K51117
? 206-00-K2167 DECAL KIT 1
SN: K51093-K51093
? 206-00-K2166 DECAL KIT 1
SN: K50476-K51092
? 206-00-K2165 DECAL KIT 1
SN: K50304-K50475
? 206-00-K2180 DECAL KIT 1
SN: K50123-K50303
? 206-00-K2163 DECAL KIT 1
SN: K50112-K50122
? 206-00-K2162 DECAL KIT 1
SN: K50081-K50111
? 206-00-K2161 DECAL KIT 1
SN: K50001-K50080
? 206-00-K2160 DECAL KIT 1
SN: K50001-K50001
? 09637-A0480 • PLATE, INSTRUCTION, AIR CLEANER ELEMENT 1
SN: K51094-
? 09637-A0640 • PLATE, INSTRUCTION, AIR CLEANER ELEMENT 1
SN: K51093-K51093
? 20E-00-K1120 • PLATE, INSTRUCTION, AIR CLEANER ELEMENT 1
SN: K50001-K51092
? 09690-P1250 • PLATE, MARK, KOMATSU (BOOM) 2
SN: K50001-
? 09690-P1250 • PLATE, MARK, KOMATSU (COUNTER WEIGHT) 1
SN: K50001-
? 09844-00050 • PLATE, EMERGENCY EXIT 1
SN: K50001-
? 09685-00002 • PLATE, OPERATING, SAFETY LOCK LEVER 1
SN: K50001-
? 09690-M0063 • PLATE, MARK, KOMATSU 1
SN: K50001-
? 09690-P0630 • PLATE, MARK, KOMATSU (BATTERY CASE) 1
SN: K50001-
? 20E-00-K1150 • PLATE, CAUTION, KEEP OFF SWING AREA 2
SN: K50001-
? 20E-00-K1140 • PLATE, CAUTION, KEEP OFF WORKING AREA 2
SN: K50001-
? 09653-A0481 • PLATE, SAFETY, RADIATOR CAP AND OIL INLET 2
SN: K50001-
? 09657-A0881 • PLATE, SAFETY, TRACK ADJUSTMENT WARNING 2
SN: K50001-
? 09667-A0481 • PLATE, SAFETY, KEEP AWAY FAN AND BELT 1
SN: K50001-
? 09803-A0481 • PLATE, SAFETY, KEEP AWAY FROM EDGE 2
SN: K50001-
? 09805-A0881 • PLATE, SAFETY, KEEP AWAY FROM EDGE 1
SN: K50001-
? 09805-C0481 • PLATE, SAFETY, HOOD 2
SN: K50001-
? 09808-A0881 • PLATE, SAFETY, BATTERY CABLE 1
SN: K50001-
? 20Y-00-K2021 • PLATE, WARNING DECAL 1
SN: K51093-
? 20Y-00-K2020 • PLATE, WARNING DECAL 1
SN: K50304-K51092
? 207-00-K1951 • PLATE, WARNING DECAL 1
SN: K50001-K50303
? 09669-0000E • PLATE, CAUTION, FUEL INLET 1
SN: K50001-
? 20Y-00-48151 • OIL CHART 1
SN: K50001-
? 09963-A1640 • TAG, DO NOT OPERATE 1
SN: K50001-
? 20Y-00-K2031 • PLATE, FUSE 1
SN: K51093-
? 20Y-00-K2030 • PLATE, FUSE 1
SN: K50304-K51092
? 20Y-00-48131 • PLATE, FUSE 1
SN: K50001-K50303
? 206-00-K1010 • PLATE, SWING AND PUMP OVERRIDE 1
SN: K50001-
? 14X-98-35181 • PLATE 2
SN: K50001-
? 14X-98-35180 • PLATE 2
SN: K50001-
? 09696-40103 • PLATE, DYNAMIC NOISE 1
SN: K50001-
? 09696-50070 • PLATE, NOISE, OPERATOR 1
SN: K50001-
? 20Y-00-K2380 • PLATE, RECOMMENDED LUBRICANT 1
SN: K50001-K50001
? 20E-00-K1710 • PLATE, CAUTION, BLUE TAG 1
SN: K50001-
? 20E-00-K1690 • PLATE, CAUTION, ANTI-FREEZE 1
SN: K50001-K51092
? 20Y-00-K2950 • PLATE, SLING POSITION 1
SN: K51113-
? 20Y-00-31840 • PLATE, SLING POSITION 1
SN: K50001-K51112
? 09960-00801 • MARK, SLING POSITION 4
SN: K50001-
? 205-00-73360 • PLATE, OPERATING, LEVEL GAUGE 1
SN: K50001-
? 09669-0000C • PLATE, CAUTION, HYDRAULIC OIL INLET 1
SN: K50001-
? 22U-00-21511 • PLATE, 12V SOCKET 1
SN: K51093-
? 22U-00-21510 • PLATE, 12V SOCKET 1
SN: K50001-K51092
? 208-00-71261 • PLATE, NOTICE 1
SN: K51093-
? 208-00-71260 • PLATE, NOTICE 1
SN: K50001-K51092
? 09960-00802 • MARK 4
SN: K50001-
? 20Y-00-41461 • PLATE, LOCK FOR FRONT LOWER WINDOW 1
SN: K51093-
? 20Y-00-41460 • PLATE, LOCK FOR FRONT LOWER WINDOW 1
SN: K50001-K51092
? 20Y-00-41530 • PLATE, ECOT 3 1
SN: K50001-
? 20Y-00-41341 • PLATE, PRE-FILTER 1
SN: K51093-
? 20Y-00-41340 • PLATE, PRE-FILTER 1
SN: K50001-K51092
? 20J-00-11271 • PLATE 1
SN: K50123-
? 09462-A0480 • PLATE, INSTRUCTION, COOLING 1
SN: K51093-
? 21U-98-31160 • PLATE, GRAVITY POSITION MARK 2
SN: K51094-
? 09845-00480 • PLATE, KOMTRAX WARNING 1
SN: K51118-
? 09601-02063 PLATE, NAME, MACHINE MODEL 1
SN: K51093-
? 09601-02061 PLATE, NAME, MACHINE MODEL 1
SN: K50001-K51092
? 04418-13060 SCREW 4
SN: K50001-K51092
? 206-00-21230 PLATE, MARK, MACHINE MODEL 1
SN: K50001-
? 206-00-21240 PLATE, MARK, MACHINE MODEL 1
SN: K50001-
? 206-00-21610 PLATE, LIFTING CAPACITY 1
SN: K50001-
? 09659-A057B PLATE, SAFETY, GAS SPRING 1
SN: K50001-
? 09659-A057B PLATE, SAFETY, GAS SPRING 1
SN: K50001-
? 09659-A057B PLATE, SAFETY, GAS SPRING 2
SN: K50001-
? 09842-A0481 PLATE, CAUTION 2
SN: K50001-
? 04418-13060 SCREW 4
SN: K50001-
? 206-00-21370 PLATE, (NOT SHOWN) 1
SN: K50001-
? 207-00-76430 PLATE, CAMERA AND MIRRORS 1
SN: K50476-
? 20Y-00-K2980 DECAL KIT (ENGINE) 1
SN: K51093-
? 6271-81-2980 • PLATE, FUEL HIGH PRESSURE 1
SN: K51093-
? 600-181-1930 • PLATE, AIR CLEANER 1
SN: K51093-
