| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-7G-01130 | Motor Assembly | 1 | SN: 20001- SCC: |
|||
| ? | 702-75-01270 | • Valve Assembly | 1 | SN: 20001- SCC: |
|||
| ? | 702-75-11110 | • • Sleeve | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-75392 | • • Seat, Valve | 1 | SN: 20001- SCC: C1 |
|||
| ? | 702-75-11130 | • • Valve | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-75620 | • • Piston | 1 | SN: 20001- SCC: C1 |
|||
| ? | 702-75-11140 | • • Spring | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-75640 | • • Rod | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-75630 | • • Screw | 1 | SN: 20001- SCC: C1 |
|||
| ? | 07000-12012 | • • O-ring | 1 | SN: 20001- SCC: C1 |
|||
| ? | 07001-02012 | • • Ring, Back-up | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-75350 | • • Nut | 1 | SN: 20001- SCC: C1 |
|||
| ? | 07000-F2020 | • • O-ring | 1 | SN: 20001- SCC: |
|||
| ? | 07001-02020 | • • Ring, Back-up | 1 | SN: 20001- SCC: |
|||
| ? | 07002-13034 | • • O-ring | 1 | SN: 20001- SCC: |
|||
| ? | 702-15-77000 | • Valve Assembly | 1 | SN: 20001- SCC: |
|||
| ? | 702-15-71220 | • • Body | 1 | SN: 20001- SCC: C1 |
|||
| ? | 702-15-71160 | • • Spool | 2 | SN: 20001- SCC: C1 |
|||
| ? | 709-70-71610 | • • Seal | 2 | SN: 20001- SCC: |
|||
| ? | 702-15-71130 | • • Spring | 2 | SN: 20001- SCC: |
|||
| ? | 702-15-71140 | • • Plug | 2 | SN: 20001- SCC: |
|||
| ? | 07002-01423 | • • O-ring | 2 | SN: 20001- SCC: |
|||
| ? | 07000-03042 | • O-ring | 1 | SN: 20001- SCC: |
|||
| ? | 07000-11009 | • O-ring | 2 | SN: 20001- SCC: |
|||
| ? | 01252-60825 | • Bolt, Hexagon Socket Head | 2 | SN: 20001- SCC: |
