| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-7G-01130 | Motor Assembly | 1 | SN: 20001- SCC: |
|||
| ? | 706-7G-03090 | • Motor Subassembly | 1 | SN: 20001- SCC: |
|||
| ? | • • Shaft, Drive | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Bearing | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Spacer | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Bearing | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Spacer Kit | 1 | SN: 20001- SCC: C2 |
||||
| ? | 706-7G-41810 | • • • Spacer, T=3.1mm | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-7G-41820 | • • • Spacer, T=3.4mm | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-7G-41830 | • • • Spacer, T=3.7mm | 1 | SN: 20001- SCC: C1 |
|||
| ? | 04064-04518 | • • Ring, Snap, for Shaft Side | 1 | SN: 20001- SCC: |
|||
| ? | 706-7E-11280 | • • Seal, Oil | 1 | SN: 20001- SCC: |
|||
| ? | 706-7G-41910 | • • Spacer | 1 | SN: 20001- SCC: |
|||
| ? | 04065-06220 | • • Ring, Snap, for Hole Side | 1 | SN: 20001- SCC: |
|||
| ? | • • Block, Cylinder | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Plate, Valve | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Pin, Dowel | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Shaft, Center | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Ring, Center | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Spring | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Retainer Kit | 1 | SN: 20001- SCC: C2 |
||||
| ? | 706-7G-41260 | • • • Retainer | 1 | SN: 20001- SCC: C1 |
|||
| ? | 706-75-42270 | • • • Screw | 7 | SN: 20001- SCC: C1 |
|||
| ? | • • Piston Subassembly | 7 | SN: 20001- SCC: C2 |
||||
| ? | • • Plate | 5 | SN: 20001- SCC: C2 |
||||
| ? | • • Disc | 4 | SN: 20001- SCC: C2 |
||||
| ? | • • Piston, Brake | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • O-ring | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • O-ring | 1 | SN: 20001- SCC: C2 |
||||
| ? | • • Spring | 6 | SN: 20001- SCC: C2 |
