| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-54-72312 | Cover | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72311 | Cover | 1 | SN: 10001-70002 SCC: |
|||
| ? | 20Y-54-71512NK | • Cover | 1 | SN: 10001- SCC: C1 |
|||
| ? | 20Y-54-71511NK | • Cover | 1 | SN: 10001-70002 SCC: C1 |
|||
| ? | 20Y-54-71970 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71980 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72260 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72270 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72280 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 205-03-71440 | • Sheet | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71590 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71680 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71790 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72510 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72520 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72540 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72550 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-72830 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71612 | Cover | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71611 | Cover | 1 | SN: 10001-70002 SCC: |
|||
| ? | 20Y-54-71622NK | • Plate | 1 | SN: 10001- SCC: C1 |
|||
| ? | 20Y-54-71621NK | • Plate | 1 | SN: 10001-70002 SCC: C1 |
|||
| ? | 20Y-54-71632 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71631 | • Sheet | 1 | SN: 10001-70002 SCC: |
|||
| ? | 20Y-54-71641 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71651 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71661 | • Sheet | 1 | SN: 10001- SCC: |
|||
| ? | 01010-81225 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-31232 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-54-71670NK | Plate | 1 | SN: 10001- SCC: |
|||
| ? | 01010-81225 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-31232 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 21T-06-11350 | Washer Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 01010-80620 | Bolt | 4 | SN: 10001- SCC: |
|||
| ? | 01643-30623 | Washer | 4 | SN: 10001- SCC: |
|||
| ? | 20Y-06-15240 | Tank | 1 | SN: 10001- SCC: |
|||
| ? | 205-03-71532 | • Cap | 1 | SN: 10001- SCC: |
|||
| ? | 205-03-71540 | • • Packing | 1 | SN: 10001- SCC: |
|||
| ? | 203-03-56650 | Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 01010-80820 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-30823 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-03-41880 | Hose | 1 | SN: 10001- SCC: |
|||
| ? | 206-03-43340 | Clip | 1 | SN: 10001- SCC: |
|||
| ? | 01010-81230 | Bolt | 7 | SN: 10001- SCC: |
|||
| ? | 01643-31232 | Washer | 7 | SN: 10001- SCC: |
|||
| ? | 205-54-76411 | Collar | 2 | SN: 10001- SCC: |
|||
| ? | 01010-81230 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-31232 | Washer | 2 | SN: 10001- SCC: |
