| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-16-04290 | Valve, Pilot | 1 | SN: 10001- SCC: |
|||
| ? | 22U-54-25660 | Seal | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-43-41760 | Seat | 1 | SN: 10001- SCC: |
|||
| ? | 01010-81025 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-31032 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 01643-31032 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-62-25360XC | Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 01010-D1035 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-71032 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 207-43-81250XC | Pedal | 1 | SN: 10001- SCC: |
|||
| ? | 01010-D1045 | Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 01643-71032 | Washer | 2 | SN: 10001- SCC: |
|||
| ? | 22U-54-25541XC | Plate | 1 | SN: 10001- SCC: |
|||
| ? | 01010-81025 | Bolt | 3 | SN: 10001- SCC: |
|||
| ? | 01643-31032 | Washer | 3 | SN: 10001- SCC: |
|||
| ? | 207-43-81220XC | Pedal | 1 | SN: 10001- SCC: |
|||
| ? | 01240-00816 | Screw | 4 | SN: 10001- SCC: |
|||
| ? | 207-43-81240 | Cap | 1 | SN: 10001- SCC: |
|||
| ? | 20T-910-8660 | Nipple | 1 | SN: 10001- SCC: |
|||
| ? | 07000-12011 | O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-62-52160 | Elbow | 2 | SN: 10001- SCC: |
|||
| ? | 02896-11008 | O-ring | 2 | SN: 10001- SCC: |
|||
| ? | 07000-12011 | O-ring | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-62-43470 | Nipple | 1 | SN: 10001- SCC: |
|||
| ? | 02896-11008 | O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 11Y-62-12140 | Nipple | 1 | SN: 10001- SCC: |
|||
| ? | 02896-11008 | O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 07000-12011 | O-ring | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-62-52330 | Hose, L=900mm | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-62-52340 | Hose, L=4100mm | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-62-52350 | Hose, L=3350mm | 1 | SN: 10001- SCC: |
|||
| ? | 208-62-72480 | Hose, L=1080mm | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-62-22790 | Band, Red | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-62-22810 | Band, Yellow | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-62-22820 | Band, Blue | 2 | SN: 10001- SCC: |
|||
| ? | 04435-51210 | Clip | 1 | SN: 10001- SCC: |
|||
| ? | 01583-11408 | Nut | 1 | SN: 10001- SCC: |
|||
| ? | 206-06-61130 | Switch | 2 | SN: 10001- SCC: |
|||
| ? | 08193-21012 | Clip | 1 | SN: 10001- SCC: |
|||
| ? | 08053-01510 | Clip | 1 | SN: 10001- SCC: |
|||
| ? | 01580-01008 | Nut | 2 | SN: 10001- SCC: |
