| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-16-04290 | Valve, Pilot | 1 | SN: 10001- SCC: |
|||
| ? | 702-16-62470 | • Valve Body | 1 | SN: 10001- SCC: C1 |
|||
| ? | 702-16-53120 | • Valve | 2 | SN: 10001- SCC: C1 |
|||
| ? | 702-16-51140 | • Shim, T=0.3MM | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54670 | • Shim, T=0.20mm | 4 | SN: 10001- SCC: |
|||
| ? | 702-16-54550 | • Spring | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54571 | • Retainer | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54560 | • Spring | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-53170 | • Piston | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-51270 | • Seal | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54580 | • Collar | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54590 | • O-ring | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54610 | • Lever | 1 | SN: 10001- SCC: C1 |
|||
| ? | 702-16-54620 | • Plate | 1 | SN: 10001- SCC: C1 |
|||
| ? | 702-16-54630 | • Shaft | 1 | SN: 10001- SCC: C1 |
|||
| ? | 702-16-54641 | • Boot | 1 | SN: 10001- SCC: |
|||
| ? | 01252-30625 | • Bolt | 2 | SN: 10001- SCC: |
|||
| ? | 702-16-54660 | • Plate | 1 | SN: 10001- SCC: |
|||
| ? | 702-16-54650 | • Plate | 2 | SN: 10001- SCC: |
|||
| ? | 702-21-07610 | • Valve, Solenoid | 1 | SN: 10001- SCC: |
|||
| ? | 700-22-11410 | • O-ring | 2 | SN: 10001- SCC: |
|||
| ? | 702-21-39450 | • O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 07000-11008 | • O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 07000-12012 | • O-ring | 1 | SN: 10001- SCC: |
|||
| ? | 702-16-62480 | • Body | 1 | SN: 10001- SCC: |
|||
| ? | 01252-60612 | • Bolt, Hexagon Socket Head | 3 | SN: 10001- SCC: |
|||
| ? | 203-60-62220 | • Bolt | 2 | SN: 10001- SCC: |
