| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 206-53-00110 | Cab Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-00091 | • Window Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-18511 | • • Frame | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11520 | • • Glass | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-51531 | • • Seal | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11551 | • • Seal | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15411 | • • Lock Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15440 | • • Case | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15470 | • • Knob | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15421 | • • Lock Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15450 | • • Case | 1 | SN: 10001- SCC: |
|||
| ? | 22B-54-15480 | • • Knob | 1 | SN: 10001- SCC: |
|||
| ? | 01435-40812 | • • Bolt | 4 | SN: 10001- SCC: |
|||
| ? | 20Y-54-52621 | • • Roller | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-54-52681 | • • Roller | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-53-12330YF | • • Pin | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-14590 | • • Handle | 2 | SN: 10001- SCC: |
|||
| ? | 01245-00616 | • • Screw, Hexagon Socket Head | 4 | SN: 10001- SCC: |
|||
| ? | 01643-70623 | • • Washer | 4 | SN: 10001- SCC: |
|||
| ? | 20Y-53-12830YF | • • Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 01245-00816 | • • Screw, Hexagon Socket Head | 2 | SN: 10001- SCC: |
|||
| ? | 01643-70823 | • • Washer, Flat | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-54-51670 | • Stopper | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-51680 | • Stopper | 1 | SN: 10001- SCC: |
|||
| ? | 01252-80616 | • Bolt, Hexagon Socket Head | 4 | SN: 10001- SCC: |
|||
| ? | 01643-70623 | • Washer | 4 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11561 | • Block Assembly | 1 | SN: 10001- SCC: |
|||
| ? | 01245-00816 | • Screw, Hexagon Socket Head | 2 | SN: 10001- SCC: |
|||
| ? | 01643-70823 | • Washer, Flat | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11661XC | • Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 01245-00816 | • Screw, Hexagon Socket Head | 2 | SN: 10001- SCC: |
|||
| ? | 01643-70823 | • Washer, Flat | 2 | SN: 10001- SCC: |
|||
| ? | 21J-06-12440 | • Switch | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11581SX | • Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11581 | • • Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11641 | • Bracket | 1 | SN: 10001- SCC: |
|||
| ? | 01435-00612 | • Bolt | 4 | SN: 10001- SCC: |
|||
| ? | 20Y-54-11611 | • Stopper | 2 | SN: 10001- SCC: |
|||
| ? | 01580-11008 | • Nut | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-54-51621 | • Striker | 2 | SN: 10001- SCC: |
|||
| ? | 01584-31008 | • Nut, Flanged | 2 | SN: 10001- SCC: |
|||
| ? | 01643-71032 | • Washer | 2 | SN: 10001- SCC: |
|||
| ? | 20Y-53-11540 | • Seal | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-54-51420 | • Seal | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-12531 | • Cover | 1 | SN: 10001- SCC: |
|||
| ? | 20Y-53-12310 | • Collar | 3 | SN: 10001- SCC: |
|||
| ? | 01245-00616 | • Screw, Hexagon Socket Head | 3 | SN: 10001- SCC: |
|||
| ? | 01643-70623 | • Washer | 3 | SN: 10001- SCC: |
