| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-12-12741 | BODY,OUTER | 1 | SN: 10001- |
|||
| ? | 421-12-12730 | BODY,INNER | 1 | SN: 10001- |
|||
| ? | 07046-47020 | PLUG | 1 | SN: 10001- |
|||
| ? | 421-12-12270 | RUBBER | 4 | SN: 10001- |
|||
| ? | 421-12-12370 | RUBBER | 4 | SN: 10001- |
|||
| ? | 421-12-12762 | FLANGE | 1 | SN: 10001- |
|||
| ? | 421-12-12752 | FLANGE | 1 | SN: 10001- |
|||
| ? | 01010-31090 | BOLT | 12 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 12 | SN: 10001- |
|||
| ? | 421-12-12220 | BEARING | 1 | SN: 10001- |
|||
| ? | 06040-06017 | BEARING | 1 | SN: 10001- |
|||
| ? | 04064-08530 | RING,SNAP | 2 | SN: 10001- |
|||
| ? | 421-12-12790 | COVER | 1 | SN: 10001- |
|||
| ? | 07012-00070 | SEAL,OIL | 1 | SN: 10001- |
|||
| ? | 07000-02125 | O-RING | 1 | SN: 10001- |
|||
| ? | 01010-51025 | BOLT | 2 | SN: 10001- |
|||
| ? | 421-12-12770 | SHAFT | 1 | SN: 10001- |
|||
| ? | 07030-01030 | BREATHER | 1 | SN: 10001- |
|||
| ? | 01010-31060 | BOLT | 12 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 12 | SN: 10001- |
|||
| ? | 421-12-12783 | COVER | 1 | SN: 10001- |
|||
| ? | 421-12-12230 | PLATE | 1 | SN: 10001- |
|||
| ? | 421-12-12241 | SEAL | 1 | SN: 10001- |
|||
| ? | 01010-30816 | BOLT | 8 | SN: 10001- |
|||
| ? | 01643-30823 | WASHER | 8 | SN: 10001- |
|||
| ? | 01010-31020 | BOLT | 6 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 6 | SN: 10001- |
