| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 41L-54-25111 | HANDRAIL,L.H. | 1 | SN: 50007- |
|||
| ? | 41L-54-25171 | HANDRAIL,R.H. | 1 | SN: 50007- |
|||
| ? | 01435-01235 | BOLT | 8 | SN: 50007- |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 50007- |
|||
| ? | 41L-54-25131 | HANDRAIL,L.H. | 1 | SN: 50003- |
|||
| ? | 41L-54-25141 | HANDRAIL,R.H. | 1 | SN: 50003- |
|||
| ? | 01435-01235 | BOLT | 8 | SN: 50003- |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 50003- |
|||
| ? | 41L-54-25151 | HANDRAIL,L.H. | 1 | SN: 50001- |
|||
| ? | 41L-54-25161 | HANDRAIL,R.H. | 1 | SN: 50001- |
|||
| ? | 01435-01230 | BOLT | 4 | SN: 50003- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 50003- |
|||
| ? | 01435-01235 | BOLT | 4 | SN: 50003- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 50003- |
|||
| ? | 428-T86-1610 | BRACKET | 4 | SN: 50001- |
|||
| ? | 428-T86-1620 | RUBBER | 4 | SN: 50001- |
|||
| ? | 01435-01050 | BOLT | 16 | SN: 50003- |
|||
| ? | 01596-01009 | NUT | 16 | SN: 50001- |
|||
| ? | 01643-31032 | WASHER | 16 | SN: 50001- |
|||
| ? | 428-T86-1630 | BRACKET | 4 | SN: 50001- |
|||
| ? | 01010-81290 | BOLT | 8 | SN: 50001- |
|||
| ? | 01596-01211 | NUT | 8 | SN: 50001- |
|||
| ? | 01643-31232 | WASHER | 16 | SN: 50001- |
|||
| ? | 428-T86-1640 | STEP | 2 | SN: 50001- |
|||
| ? | 428-T86-1650 | PLATE | 8 | SN: 50001- |
|||
| ? | 41L-54-24111 | BRACKET,L.H. | 1 | SN: 50010- |
|||
| ? | □41L-54-24110 | BRACKET,L.H. | 1 | SN: 50001-50009 |
|||
| ? | 41L-54-24121 | BRACKET,R.H. | 1 | SN: 50010- |
|||
| ? | □41L-54-24120 | BRACKET,R.H. | 1 | SN: 50001-50009 |
|||
| ? | 01010-81230 | BOLT | 8 | SN: 50001- |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 50001- |
|||
| ? | 428-T86-1710 | CABLE | 2 | SN: 50007- |
|||
| ? | 428-54-22150 | HOSE | 2 | SN: 50007- |
|||
| ? | 428-54-22170 | JOINT | 2 | SN: 50007- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 50007- |
|||
| ? | 04052-11038 | PIN | 2 | SN: 50007- |
|||
| ? | 428-T86-1721 | PLATE | 2 | SN: 50007- |
