| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (41L-56-21010) | CAB ASS'Y,(EXCEPT JAPAN) | 1 | SN: 50001- |
|||
| ? | (41L-56-21030) | CAB ASS'Y,(KOMATSU HANOMAG) | 1 | SN: 50001- |
|||
| ? | (41L-56-21050) | CAB ASS'Y | 1 | SN: 50008- |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-20A0. | ||||||
| ? | (421-926-2101) | • DOOR ASS'Y,L.H. | 1 | SN: 50001- |
|||
| ? | (41K-926-2300) | • DOOR ASS'Y,L.H. (KOMATSU HANOMAG) | 1 | SN: 50001- |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-11A0 TO K0210-13A0. | ||||||
| ? | 423-56-21810 | • • COVER | 1 | SN: 50001- |
|||
| ? | 423-56-21820 | • • COVER | 1 | SN: 50001- |
|||
| ? | 421-56-21430 | • • PAD,L.H. | 1 | SN: 50001- |
|||
| ? | 421-56-21460 | • • • FASTENER | 8 | SN: 50001- |
|||
| ? | 421-56-21490 | • • • SEAL | 1 | SN: 50001- |
|||
| ? | 421-56-21470 | • • FASTENER | 8 | SN: 50001- |
|||
| ? | 01220-40408 | • • SCREW | 8 | SN: 50001- |
|||
| ? | 423-56-21721 | • • PLATE | 1 | SN: 50001- |
|||
| ? | 423-56-21760 | • • COVER,L.H. | 1 | SN: 50001- |
|||
| ? | 423-56-21750 | • • SPRING | 1 | SN: 50001- |
|||
| ? | 01435-00610 | • • BOLT | 4 | SN: 50001- |
|||
| ? | 423-56-21730 | • • ROD | 1 | SN: 50001- |
|||
| ? | 423-56-21740 | • • KNOB | 1 | SN: 50001- |
|||
| ? | 421-56-11640 | • • SPRING | 1 | SN: 50001- |
|||
| ? | 421-56-11840 | • • PIN | 1 | SN: 50001- |
|||
| ? | 421-56-11652 | • • BUSHING | 2 | SN: 50001- |
|||
| ? | 423-56-21780 | • • PLATE | 1 | SN: 50001- |
|||
| ? | 01435-00616 | • • BOLT | 1 | SN: 50001- |
|||
| ? | 01643-31232 | • • WASHER | 1 | SN: 50001- |
|||
| ? | 01596-01009 | • • NUT | 1 | SN: 50001- |
|||
| ? | 421-62-14740 | • • WASHER | 1 | SN: 50001- |
|||
| ? | 421-56-11652 | • • BUSHING | 1 | SN: 50001- |
|||
| ? | 423-56-21350 | • • GRIP | 1 | SN: 50001- |
|||
| ? | 01435-01025 | • • BOLT | 2 | SN: 50001- |
|||
| ? | 363-54-31450 | • • CAP | 2 | SN: 50001- |
|||
| ? | 09415-01008 | • • CAP | 1 | SN: 50001- |
|||
| ? | 01023-70612 | • • SCREW | 2 | SN: 50001- |
|||
| ? | 417-56-21540 | • • HINGE | 2 | SN: 50001- |
|||
| ? | 01010-80825 | • • BOLT | 4 | SN: 50001-. |
|||
| ? | 01643-30823 | • • WASHER | 4 | SN: 50001- |
|||
| ? | 421-926-2950 | • • CUSHION | 1 | SN: 50001- |
|||
| ? | 01023-70416 | • • SCREW | 1 | SN: .- |
|||
| ? | 01023-70214 | • • SCREW | 1 | SN: 50001-. |
