| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07425-72101 | PUMP ASS'Y,LUBRICATING OIL | 2 | SN: 1008-@ |
|||
| ? | 01010-51030 | BOLT | 8 | SN: 1008-@ |
|||
| ? | 01602-21030 | WASHER,SPRING | 8 | SN: 1008-@ |
|||
| ? | 07000-22065 | O-RING | 2 | SN: 1008-@ |
|||
| ? | 07231-10422 | ELBOW | 2 | SN: 1008-1083 |
|||
| ? | 07000-03017 | O-RING | 2 | SN: 1008-@ |
|||
| ? | 07239-12009 | NUT | 2 | SN: 1008-@ |
|||
| ? | 07042-20108 | PLUG | 2 | SN: 1008-1083 |
|||
| ? | (☒07042-00108) | PLUG | 2 | SN: (1008-1083) |
|||
| ? | 281-01-17370 | TUBE | 2 | SN: 1008-@ |
|||
| ? | 6631-51-9750 | CLAMP | 2 | SN: 1008-@ |
|||
| ? | 07042-20211 | PLUG | 2 | SN: 1008-@ |
|||
| ? | 07235-10628 | ELBOW | 2 | SN: 1008-@ |
|||
| ? | 07000-23022 | O-RING | 2 | SN: 1008-@ |
|||
| ? | 07102-20611 | HOSE | 2 | SN: 1008-@ |
|||
| ? | (☒07100-20611) | HOSE | 2 | SN: (1133-1286) |
|||
| ? | (☒07100-20610) | HOSE | 2 | SN: (1008-1132) |
|||
| ? | 07100-20414 | HOSE | 2 | SN: 1008-1083 |
|||
| ? | 07042-20108 | PLUG | 2 | SN: 1008-1083 |
|||
| ? | 07231-10422 | ELBOW | 2 | SN: 1008-1083 |
|||
| ? | 07000-23017 | O-RING | 2 | SN: 1008-1083 |
|||
| ? | 07239-12009 | NUT | 2 | SN: 1008-1083 |
|||
| ? | 07042-20108 | PLUG | 2 | SN: 1008-1083 |
|||
| ? | 281-01-17231 | ADAPTER | 2 | SN: 1008-1083 |
|||
| ? | 07000-22014 | O-RING | 2 | SN: 1008-1083 |
|||
| ? | 07372-21030 | BOLT | 4 | SN: 1008-1083 |
|||
| ? | 01602-21030 | WASHER,SPRING | 4 | SN: 1008-1083 |
|||
| ? | 01010-51030 | BOLT | 4 | SN: 1008-@ |
|||
| ? | 01602-21030 | WASHER,SPRING | 4 | SN: 1008-@ |
|||
| ? | 07000-23035 | O-RING | 2 | SN: 1008-@ |
|||
| ? | 281-01-17310 | TUBE | 2 | SN: 1008-1083 |
|||
| ? | 07000-22018 | O-RING | 2 | SN: 1008-1083 |
|||
| ? | 281-01-17320 | GAUGE,OIL LEVEL | 2 | SN: 1008-1083 |
|||
| ? | 07213-51013 | CONNECTOR | 2 | SN: 1008-1083 |
|||
| ? | 08036-11210 | CLIP | 2 | SN: 1008-1083 |
|||
| ? | 6657-22-4272 | COVER | 2 | SN: 1008-@ |
|||
| ? | 281-01-17341 | TUBE | 2 | SN: 1008-@ |
|||
| ? | 07030-03034 | BREATHER | 2 | SN: 1008-@ |
|||
| ? | 07005-03016 | GASKET | 2 | SN: 1008-@ |
|||
| ? | 07371-00638 | FLANGE,SPLIT | 8 | SN: 1008-@ |
|||
| ? | 07372-20830 | BOLT | 8 | SN: 1008-@ |
|||
| ? | 01602-20825 | WASHER,SPRING | 8 | SN: 1008-@ |
|||
| ? | 07213-50813 | CONNECTOR | 4 | SN: 1008-@ |
|||
| ? | 281-01-17490 | TUBE | 2 | SN: 1008-1083 |
|||
| ? | 08036-00814 | CLIP | 2 | SN: 1008-1083 |
|||
| ? | 07000-02012 | O-RING | 8 | SN: 1008-1083 |
|||
| ? | 6631-51-9590 | BOLT,EYE | 4 | SN: 1008-@ |
|||
| ? | 281-01-16310 | TUBE | 2 | SN: 1008-1083 |
|||
| ? | 08036-10814 | CLIP | 2 | SN: 1008-1083 |
|||
| ? | 01010-51025 | BOLT | 3 | SN: 1008-@ |
|||
| ? | 01602-21030 | WASHER,SPRING | 3 | SN: 1008-@ |
|||
| ? | 07000-23025 | O-RING | 2 | SN: 1008-@ |
