| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 04434-51010 | CLAMP | 1 | SN: F00003- |
|||
| ? | 01010-80816 | BOLT | 2 | SN: F00003- |
|||
| ? | 01643-10823 | WASHER | 3 | SN: F00003- |
|||
| ? | 04434-52112 | CLAMP | 1 | SN: F00003- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: F00003- |
|||
| ? | 01643-11032 | WASHER | 2 | SN: F00003- |
|||
| ? | 08034-20519 | CLAMP | 6 | SN: F00003- |
|||
| ? | 08034-20519 | CLAMP | 15 | SN: F00003- |
|||
| ? | 42N-06-11970 | WIRING HARNESS, ENGINE ALTERNATOR | 1 | SN: F00003- |
|||
| ? | 01580-11008 | NUT, STOP | 1 | SN: F00003- |
|||
| ? | 01602-21030 | WASHER | 1 | SN: F00003- |
|||
| ? | 42N-06-11150 | WIRING HARNESS, ALTERNATOR | 1 | SN: F00003- |
|||
| ? | 01010-81025 | BOLT | 1 | SN: F00003- |
|||
| ? | 21D-09-21420 | NUT | 2 | SN: F00003- |
|||
| ? | 01601-20513 | SPRING WASHER | 2 | SN: F00003- |
|||
| ? | 01580-10806 | NUT | 1 | SN: F00003- |
|||
| ? | 01602-20825 | WASHER | 1 | SN: F00003- |
|||
| ? | 42N-06-11160 | WIRING HARNESS, ENGINE | 1 | SN: F00003- |
|||
| ? | 37A-06-11960 | CLOGGING INDICATOR | 1 | SN: F00003- |
|||
| ? | 42N-06-11641 | BRACKET | 1 | SN: F00003- |
|||
| ? | 01010-80820 | BOLT | 1 | SN: F00003- |
|||
| ? | 21D-06-13220 | CLAMP | 10 | SN: F00003- |
|||
| ? | 42N-06-11130 | GROUND FRAME CABLE | 1 | SN: F00003- |
|||
| ? | 01010-81220 | BOLT | 1 | SN: F00003- |
|||
| ? | 01643-11232 | WASHER | 1 | SN: F00003- |
|||
| ? | SEE FIG. 1430 | 1430 |
