| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 42N-62-11210 | UNION | 2 | SN: F00003- |
|||
| ? | 02896-11012 | • O-RING | 1 | SN: F00003- |
|||
| ? | 07002-11823 | • O-RING | 1 | SN: F00003- |
|||
| ? | 42N-62-17480 | HOSE | 1 | SN: F00003- |
|||
| ? | 42N-62-17490 | HOSE | 1 | SN: F00003- |
|||
| ? | 226-09-12680 | UNION | 2 | SN: F00003- |
|||
| ? | 02896-11012 | • O-RING | 1 | SN: F00003- |
|||
| ? | 37B-09-15617 | • O-RING | 1 | SN: F00003- |
|||
| ? | 226-09-12740 | ELBOW | 2 | SN: F00003- |
|||
| ? | 02896-11012 | • O-RING | 1 | SN: F00003- |
|||
| ? | 37B-09-15617 | • O-RING | 1 | SN: F00003- |
|||
| ? | 42N-64-11310 | SOLENOID VALVE, ASSY. | 1 | SN: F00003- |
|||
| ? | • COIL | 1 | SN: F00003- |
||||
| ? | 22E-60-18340 | • KIT, RING NUT | 1 | SN: F00003- |
|||
| ? | 01010-80890 | BOLT | 2 | SN: F00003- |
|||
| ? | 01643-10823 | WASHER | 4 | SN: F00003- |
|||
| ? | 21D-09-24408 | NUT | 2 | SN: F00003- |
|||
| ? | 42N-62-17130 | PIPE | 1 | SN: F00003- |
|||
| ? | 42N-62-17120 | PIPE | 1 | SN: F00003- |
|||
| ? | 42N-62-11890 | HOSE | 2 | SN: F00003- |
|||
| ? | SEE FIG. 6600 | 6600 | |||||
| ? | SEE FIG. 6635 | 6635 |
