| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-18-17203) | CONTROL VALVE, ASSY. | 1 | SN: F00003- |
|||
| ? | ☆ | • SPOOL | 2 | SN: F00003- |
|||
| ? | ☆ | • PLUG | 4 | SN: F00003- |
|||
| ? | ☆ | • O-RING | 4 | SN: F00003- |
|||
| ? | 723-26-14510 | • SPRING | 1 | SN: F00003- |
|||
| ? | 709-26-11450 | • SPRING | 1 | SN: F00003- |
|||
| ? | 723-26-15110 | • COVER | 2 | SN: F00003- |
|||
| ? | 723-26-15121 | • RETAINER | 2 | SN: F00003- |
|||
| ? | 575-41-17420 | • O-RING | 2 | SN: F00003- |
|||
| ? | 01252-60630 | • BOLT | 4 | SN: F00003- |
|||
| ? | 01641-20608 | • WASHER | 4 | SN: F00003- |
|||
| ? | 723-11-17330 | • RETAINER | 1 | SN: F00003- |
|||
| ? | 723-11-17341 | • SPRING | 1 | SN: F00003- |
|||
| ? | 723-11-17361 | • BOLT | 1 | SN: F00003- |
|||
| ? | 723-11-27880 | • COVER | 4 | SN: F00003- |
|||
| ? | 723-11-37220 | • COVER | 1 | SN: F00003- |
|||
| ? | 722-12-19120 | • O-RING | 6 | SN: F00003- |
|||
| ? | 723-11-17353 | • SEAT, NOZZLE SPRING | 1 | SN: F00003- |
|||
| ? | 01252-60640 | • BOLT | 6 | SN: F00003- |
|||
| ? | 01252-60620 | • BOLT | 2 | SN: F00003- |
