| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-1U-00112) | HYDRAULIC PUMP, ASSY. | 1 | SN: F00758- |
|||
| ? | (708-1U-01114) | • PUMP, ASSY. | 1 | SN: F00758- |
|||
| ? | ☆ | • • SCREW | 2 | SN: F00758- |
|||
| ? | 07000-12011 | • • O-RING | 2 | SN: F00758- |
|||
| ? | 01643-31232 | • • WASHER | 2 | SN: F00758- |
|||
| ? | 01582-11210 | • • NUT | 2 | SN: F00758- |
|||
| ? | ★708-3T-14120 | • • SPRING | 1 | SN: F00758- |
|||
| ? | ★708-1W-44110 | • • PISTON, ASSY. | 1 | SN: F00758- |
|||
| ? | ★708-1U-13310 | • • PISTON, ASSY. | 7 | SN: F00758- |
|||
| ? | ★708-1U-13341 | • • RETAINER PLATE | 1 | SN: F00758- |
|||
| ? | ★708-1W-43350 | • • SLEEVE | 1 | SN: F00758- |
|||
| ? | ★708-3T-13360 | • • PIN | 3 | SN: F00758- |
|||
| ? | ★708-1U-13110 | • • CYLINDER BLOCK | 1 | SN: F00758- |
|||
| ? | ★708-1W-43130 | • • SEAT | 2 | SN: F00758- |
|||
| ? | ★708-1W-43140 | • • SPRING | 1 | SN: F00758- |
|||
| ? | ★04065-04818 | • • RING, SNAP | 1 | SN: F00758- |
|||
| ? | ★708-1U-13211 | • • PLATE VALVE | 1 | SN: F00758- |
|||
| ? | ★720-68-19610 | • • PIN | 1 | SN: F00758- |
