| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 427-62-13421 | TUBE | 1 | SN: 10501- |
|||
| ? | 427-62-13420 | TUBE | 1 | SN: 10001-10499 |
|||
| ? | 07000-F3038 | O-RING | 1 | SN: 10054- |
|||
| ? | □07000-13038 | O-RING | 1 | SN: 10001-10053 |
|||
| ? | 01010-81250 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 10001- |
|||
| ? | (702-23-41901) | VALVE ASS'Y,CHECK (SEE FIG.6245) | 1 | SN: 10001- |
|||
| ? | (☒702-23-41900) | VALVE ASS'Y,CHECK (SEE FIG.6245) | 1 | SN: (10001-10064) |
|||
| ? | 07000-F3038 | O-RING | 1 | SN: 10054- |
|||
| ? | □07000-13038 | O-RING | 1 | SN: 10001-10053 |
|||
| ? | 427-62-13432 | TUBE | 1 | SN: 10585- |
|||
| ? | 427-62-13431 | TUBE | 1 | SN: 10501-10584 |
|||
| ? | 427-62-13430 | TUBE | 1 | SN: 10001-10499 |
|||
| ? | 07000-F3045 | O-RING | 1 | SN: 10054- |
|||
| ? | □07000-13045 | O-RING | 1 | SN: 10001-10053 |
|||
| ? | 01011-81225 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 10001- |
|||
| ? | 427-62-15680 | HOSE | 2 | SN: 10001- |
|||
| ? | (☒07098-01415) | HOSE | 2 | SN: (10001-10059) |
|||
| ? | 07000-F3048 | O-RING | 4 | SN: 10054- |
|||
| ? | □07000-13048 | O-RING | 4 | SN: 10001-10053 |
|||
| ? | 07371-51470 | FLANGE,SPLIT | 8 | SN: 10001- |
|||
| ? | 01010-81455 | BOLT | 16 | SN: 10001- |
|||
| ? | 01643-31445 | WASHER | 16 | SN: 10001- |
|||
| ? | 427-62-13440 | BLOCK,R.H. | 1 | SN: 10001- |
|||
| ? | 07042-20108 | PLUG | 1 | SN: 10001- |
|||
| ? | 01010-81255 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 10001- |
|||
| ? | 427-62-15730 | HOSE | 1 | SN: 10001- |
|||
| ? | (☒07098-02022) | HOSE | 1 | SN: (10001-10061) |
|||
| ? | 07000-F2060 | O-RING | 2 | SN: 10054- |
|||
| ? | □07000-12060 | O-RING | 2 | SN: 10001-10053 |
|||
| ? | 07371-52080 | FLANGE,SPLIT | 4 | SN: 10001- |
|||
| ? | 01010-81870 | BOLT | 8 | SN: 10001- |
|||
| ? | 01643-31845 | WASHER | 8 | SN: 10001- |
|||
| ? | 427-62-13191 | TUBE | 1 | SN: 10679- |
|||
| ? | ▩427-62-13190 | TUBE | 1 | SN: 10001-10678 |
|||
| ? | (427-62-13191{707-01-03210¤} | ||||||
| ? | 427-44-11111) | ||||||
| ? | 427-871-1111 | TUBE,(FOR HIGH LIFT) | 1 | SN: 10679- |
|||
| ? | ▩427-871-1110 | TUBE,(FOR HIGH LIFT) | 1 | SN: 10001-10678 |
|||
| ? | (427-871-1111{707-01-02490¤} | ||||||
| ? | 427-871-1122) | ||||||
| ? | 07000-F2060 | O-RING | 1 | SN: 10054- |
|||
| ? | □07000-12060 | O-RING | 1 | SN: 10001-10053 |
|||
| ? | 01011-81830 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31845 | WASHER | 4 | SN: 10001- |
|||
| ? | 01010-81840 | BOLT | 2 | SN: 10001- |
|||
| ? | 01643-31845 | WASHER | 2 | SN: 10001- |
|||
| ? | 427-62-13371 | BRACKET,R.H. | 1 | SN: 10001- |
|||
| ? | 01435-01225 | BOLT | 3 | SN: 10501- |
|||
| ? | □01010-51230 | BOLT | 3 | SN: 10001-10499 |
|||
| ? | 01643-31232 | WASHER | 3 | SN: 10001-10499 |
|||
| ? | 07283-34354 | CLIP | 4 | SN: 10001- |
|||
| ? | 07283-54353 | SEAT | 4 | SN: 10001- |
|||
| ? | 01597-01009 | NUT | 8 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 8 | SN: 10001- |
