| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 427-60-15242 | TANK,HYDRAULIC | 1 | SN: 10060- |
|||
| ? | □427-60-15241 | TANK,HYDRAULIC | 1 | SN: 10001-10059 |
|||
| ? | 421-60-11622 | GAUGE,SIGHT | 1 | SN: 10001- |
|||
| ? | (☒421-60-11621) | GAUGE,SIGHT | 1 | SN: (10001-10499) |
|||
| ? | 07002-15234 | O-RING | 1 | SN: 10001- |
|||
| ? | 19M-04-11220 | CAP | 1 | SN: 10001- |
|||
| ? | 07050-21202 | • GASKET | 1 | SN: 10001- |
|||
| ? | 07056-18416 | STRAINER | 1 | SN: 10001- |
|||
| ? | 426-60-15120 | COVER,TOP | 1 | SN: 10001- |
|||
| ? | 07000-12135 | O-RING | 1 | SN: 10001- |
|||
| ? | 01010-81030 | BOLT | 6 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 6 | SN: 10001- |
|||
| ? | 424-60-15211 | BREATHER ASS'Y | 3 | SN: 10001- |
|||
| ? | 285-62-17320 | • ELEMENT | 1 | SN: 10001- |
|||
| ? | 424-60-15220 | • RING,SNAP | 1 | SN: 10001- |
|||
| ? | 419-60-15370 | • O-RING | 2 | SN: 10001- |
|||
| ? | 419-60-15380 | • O-RING | 1 | SN: 10001- |
|||
| ? | 419-60-15390 | • O-RING | 1 | SN: 10001- |
|||
| ? | 427-N36-1110 | BREATHER ASS'Y,(FOR SANDY AND DUSTY TERRAIN) | 3 | SN: 10001- |
|||
| ? | 427-N36-1120 | • ELEMENT | 1 | SN: 10001- |
|||
| ? | 424-60-15220 | • RING,SNAP | 1 | SN: 10001- |
|||
| ? | 419-60-15370 | • O-RING | 2 | SN: 10001- |
|||
| ? | 419-60-15380 | • O-RING | 1 | SN: 10001- |
|||
| ? | 419-60-15390 | • O-RING | 1 | SN: 10001- |
|||
| ? | 427-60-15320 | STRAINER | 1 | SN: 10001- |
|||
| ? | 427-60-15171 | ROD | 1 | SN: 10001- |
|||
| ? | 12R-60-11230 | SPRING | 1 | SN: 10001- |
|||
| ? | 427-60-15261 | FLANGE | 1 | SN: 10674- |
|||
| ? | □427-60-15260 | FLANGE | 1 | SN: 10001-10673 |
|||
| ? | 07000-15240 | O-RING | 1 | SN: 10001- |
|||
| ? | 01435-01230 | BOLT | 6 | SN: 10501- |
|||
| ? | □01010-51235 | BOLT | 6 | SN: 10001-10499 |
|||
| ? | 01643-31232 | WASHER | 6 | SN: 10001-10499 |
|||
| ? | 427-60-15270 | COVER,BOTTOM | 1 | SN: 10001- |
|||
| ? | 07000-15335 | O-RING | 1 | SN: 10001- |
|||
| ? | 01435-01230 | BOLT | 8 | SN: 10501- |
|||
| ? | □01010-51235 | BOLT | 8 | SN: 10001-10499 |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 10001-10499 |
|||
| ? | 6127-21-5601 | VALVE ASS'Y | 1 | SN: 10001- |
|||
| ? | ☆ | • BODY | 1 | SN: 10001- |
|||
| ? | 04020-00514 | • PIN,DOWEL | 1 | SN: 10001- |
|||
| ? | 6127-21-5620 | • VALVE | 1 | SN: 10001- |
|||
| ? | 6127-21-5630 | • PLUG | 1 | SN: 10001- |
|||
| ? | 07000-13035 | O-RING | 1 | SN: 10001- |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 10001- |
|||
| ? | 427-60-15190 | COVER | 1 | SN: 10001- |
|||
| ? | 07000-15185 | O-RING | 1 | SN: 10001- |
|||
| ? | 01435-01230 | BOLT | 8 | SN: 10501- |
|||
| ? | □01010-51235 | BOLT | 8 | SN: 10001-10499 |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 10001-10499 |
|||
| ? | 426-60-15180 | COVER | 1 | SN: 10001- |
|||
| ? | 07000-12135 | O-RING | 1 | SN: 10001- |
|||
| ? | 01435-01025 | BOLT | 6 | SN: 10501- |
|||
| ? | □01010-51030 | BOLT | 6 | SN: 10001-10499 |
|||
| ? | 01643-31032 | WASHER | 6 | SN: 10001-10499 |
|||
| ? | 427-60-15230 | BRACKET | 2 | SN: 10001- |
|||
| ? | 01010-62455 | BOLT | 8 | SN: 10001- |
|||
| ? | 01643-32460 | WASHER | 8 | SN: 10001- |
|||
| ? | 01010-62465 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-32460 | WASHER | 8 | SN: 10001- |
|||
| ? | 01580-02419 | NUT | 4 | SN: 10001- |
|||
| ? | 07378-11400 | HEAD,SLEEVE | 1 | SN: 10001- |
|||
| ? | 07000-13048 | O-RING | 1 | SN: 10001- |
|||
| ? | 07371-31465 | FLANGE,SPLIT | 2 | SN: 10001- |
|||
| ? | 07372-21240 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-51232 | WASHER | 4 | SN: 10001- |
|||
| ? | 07378-12000 | HEAD,SLEEVE | 1 | SN: 10001- |
|||
| ? | 07000-12060 | O-RING | 1 | SN: 10001- |
|||
| ? | 07371-32076 | FLANGE,SPLIT | 2 | SN: 10001- |
|||
| ? | 07372-21240 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-51232 | WASHER | 4 | SN: 10001- |
